Based on the 12/13th-generation Intel Core processor, North China Industrial Control has launched the new industrial control board ATX-6159, which provides more powerful AI-accelerated computing performance with more performance cores and energy efficiency cores. Support DDR5 4800MHz, the entire board up to 128GB of running memory, and support 4*SATA 3.0 and 1*M_KEY M.2 2280 NVME SSD for caching and further expansion of storage capacity.
According to the White Paper on Cloud Computing (2023) released by the China Academy of Information and Communications Technology, China's cloud computing market has reached 445 billion yuan in 2022, with a growth rate of 40.9%, and is expected to exceed one trillion yuan in 2025. As a key industry in the development of digital economy, China's cloud computing market has good prospects for development.
In line with the development trend, North China Industrial Control has accelerated the application of high-performance processors from Intel, Ruixin Micro, Feideng and other platforms to the innovative research and development of embedded computers, and successfully launched a series of products with powerful data processing capabilities, large memory capacity, rich functional interfaces, high security and high reliability, including embedded motherboards, embedded quasi-systems and industrial machines. For cloud computing technology field
additional code layout.Based on the 12/13th-generation Intel Core processor, North China Industrial Control has launched the new industrial control board ATX-6159, which
provides more powerful AI-accelerated computing performance with more performance cores and energy efficiency cores. Support DDR5 4800MHz, the entire board up to 128GB of running memory, and support 4*SATA 3.0 and 1*M_KEY M.2 2280 NVME SSD for caching and further expansion of storage capacity.
In terms of network communication, ATX-6159 supports adaptive RJ45 Gigabit Ethernet /4G/5G/Wifi/ Bluetooth /SIM, It also supports multiple RS232/RS422/RS485 interfaces and USB3.2 GEN1 5Gbps/USB2.0 interfaces to achieve higher rate data transmission and interconnection of
multiple smart devices.In addition, the ATX-6159 also supports VGA, HDMI, and DP display interfaces, and supports 1*PCIe x16(16-lanes) GEN5 to meet the mechanical installation requirements of the RTX3080/4090 large graphics card. Support Line out, Mic in, Line in, AMP multiple audio interfaces, as well as multiple PCI, PCIe, GPIO and other functional interfaces to achieve
multiple expansion.
The ATX-6159 integrates TPM2.0, Intel AMT, and Intel vPro Technology to enhance security based on dedicated hardware (this function is not supported when the Z690/H610 bridge is installed), and is deeply compatible with Windows 10 and Linux systems. And developed the software watchdog function, can provide a more secure and stable system operating environment. Small size (305mmx 244mm), easy to deploy, can meet the multi-industry customer business system cloud computing technology development and
application requirements.Based on Rockchip RK3588 oct-core processor, North China Industrial Control launched the EMB-3582 industrial control board with 6 TOPs NPU, supporting INT4/INT8/INT16/FP16 hybrid operation. Onboard 4/8GB LPDDR4X memory, and support SATA, eMMC, TF extended storage capacity; Integrated Mali-G610 MP4 quad-core GPU, support HDMI_TX, HDMI_RX, dual-channel 24bit LVDS multiple display interfaces, can achieve 8K ultra HD display and multi-screen display.
North China EMB-3582 is equipped with rich I/O function interfaces, supports Gigabit Ethernet /Wifi/ Bluetooth (optional wifi6/BT5.0), supports Mini-PCIe expansion 4G module and M.2 interface to connect to 5G module. And multiple USB3.0/USB2.0, COM
interfaces to provide flexible network application environment; Support Headphone, MIC-IN, 5W AMP multiple audio interfaces, as well as 100Pin connector, GPIO, CAN, FAN and other I/O functional interfaces to achieve a variety of expansion.
In addition, North China Industrial Control based on the EMB-3582 motherboard also launched the embedded quasi system BIS-6390ARA-C10, the product also has high computing power, 8K ultra HD video display capability, rich functional interface and industrial grade ruggediveness and other technical advantages, can provide multi-industry customers with integrated industrial control hardware solutions for cloud computing
technology applications.Based on the E2000Q processor, North China Industrial Control launched the industrial control board EMB-3551, integrating 2 FTC664 and 2 FTC310 processor cores, which can adapt to different workloads. Support single-precision, double-precision floating-point operation instructions, ASIMD processing instructions and hardware virtualization to achieve more powerful data processing; Supports PSPA security standard 1.0, security mechanism based on domain isolation, and integrated ROM as a trusted
boot root to meet security and trust requirements in complex application scenarios. Power consumption can be reduced through power off, clock off, DVFS, core off, and frequency reduction operations.
The North China EMB-3551 supports 4GB DDR4 memory on board, and supports SATA3.0 and M.2 NVMe for cache and TF card slot to further expand storage capacity. Support Gigabit Ethernet, onboard Wifi, M.2 BKEY interface to achieve 4G/5G network access, as well as multiple USB3.0/USB2.0, COM interfaces, with flexible network application environment; Support DP, dual-channel 24bit LVDS display interface, Headphone, MIC-IN, 5W AMP multiple audio interfaces, as well as PCIE slots, CAN, buzzer, POWER indicator and multiple GPIO/SPI/I2C (optional) signals to achieve a
variety of peripheral access.EMB-3551 ADAPTS to Galaxy Kirin embedded operating system V10, and develops a watchdog function to provide customers with a more secure and
stable system operating environment. It can meet the requirements of wide temperature operation ranging from 0 ° C to 60 ° C, and can operate stably under various conditions such as complex electromagnetic environment. Small size (146mm x 120 mm), suitable for multiple scenes.
