The MAGNETEK A4-103-000 is a high-performance AC drive controller designed for industrial motor control applications. Engineered to optimize speed and torque regulation in various machinery, this drive belongs to MAGNETEK’s advanced A4 series, which combines reliability with precision control.
The MAGNETEK A4-103-000 is a high-performance AC drive controller designed for industrial motor control applications. Engineered to optimize speed and torque regulation in various machinery, this drive belongs to MAGNETEK’s advanced A4 series, which combines reliability with precision control. The A4-103-000 features a compact design suitable for space-constrained environments, while its robust circuitry ensures stable operation in demanding industrial settings. It supports multiple communication protocols, enabling seamless integration with PLCs and automation systems. Valued for its energy efficiency and diagnostic capabilities, the drive enhances system productivity by minimizing downtime and reducing power consumption.
| Parameter |
Value |
| Product Model |
MAGNETEK A4-103-000 |
| Manufacturer |
MAGNETEK |
| Product Type |
AC Drive Controller |
| Power Rating |
3 HP (2.2 kW) |
| Input Voltage |
200–240 VAC, single-phase (230 VAC nominal) |
| Output Voltage |
0–240 VAC (variable) |
| Frequency Range |
0–400 Hz |
| Control Method |
Vector control with sensorless operation |
| Communication Interfaces |
RS-485 (Modbus RTU), optional Ethernet (via expansion module) |
| Protection Features |
Overvoltage, overcurrent, short-circuit, over-temperature protection |
| Operating Temperature |
-10°C to +50°C (with derating above 40°C) |
| Dimensions (W x H x D) |
152 mm x 241 mm x 184 mm |
| Weight |
4.5 kg |
| Mounting |
Panel-mounted, wall-mounted |
| Certifications |
UL, CE, cUL |
The MAGNETEK A4-103-000 offers precise motor control through its vector control technology, enabling smooth operation across varying loads. Its 3 HP rating makes it ideal for applications such as conveyor systems, pumps, and fans in manufacturing, food processing, and material handling industries. The drive’s energy-saving design reduces power consumption by up to 30% compared to traditional starters, while its regenerative braking capability converts kinetic energy back to electrical energy, further optimizing efficiency.
Diagnostic tools within the
A4-103-000 provide real-time monitoring of motor health, including fault codes and performance metrics, simplifying maintenance and reducing downtime. The drive’s user-friendly interface allows for quick parameter setup, and its modular design supports easy integration of optional accessories like Ethernet modules or braking resistors. With a wide input voltage range and robust protection features, the drive ensures reliable operation even in environments with voltage fluctuations or transient spikes.
- MAGNETEK A4-105-000 – 5 HP variant with higher current capacity for larger motors.
- MAGNETEK A4-003-000 – 0.5 HP model for smaller-scale applications.
- MAGNETEK A4-103-001 – Version with built-in Ethernet communication for industrial networks.
- MAGNETEK A4-103-002 – Stainless steel enclosure variant for washdown environments.
- MAGNETEK A4-203-000 – Three-phase input version for 3 HP motors in commercial setups.
- MAGNETEK GPD300-103 – Previous-generation drive with basic functionality, compatible with legacy systems.
At Hainan Jinlin Electromechanical Equipment Co., Ltd., we specialize in providing industrial automation solutions as a certified partner of leading brands like MAGNETEK. Our team offers professional pre-sale technical support to help select the right drive for your application, along with post-sale services including installation guidance and maintenance. All products, including the
MAGNETEK A4-103-000, come with a one-year warranty. If you need a model not listed here, contact us via
WhatsApp or email at JLLucky33@qq.com for personalized assistance.
