The MAGNETEK A5-206-001 is a high-performance industrial drive module designed for precise motor control in manufacturing and process automation systems. Part of MAGNETEK’s advanced drive series, this model delivers reliable speed and torque regulation for AC motors,
Product Overview
The MAGNETEK A5-206-001 is a high-performance industrial drive module designed for precise motor control in manufacturing and process automation systems. Part of MAGNETEK’s advanced drive series, this model delivers reliable speed and torque regulation for AC motors, making it ideal for applications requiring dynamic performance, such as conveyor systems, packaging machinery, and material handling equipment. The A5-206-001 integrates seamlessly with existing PLC and DCS setups, offering robust protection features and diagnostic capabilities to minimize downtime. Its compact design and efficient power management enhance system reliability, while compatibility with standard communication protocols ensures easy integration into complex automation networks. The module’s durability and precision control make it a valuable asset for industries seeking to optimize operational efficiency.
Technical Specifications
| Parameter |
Value |
| Product Model |
MAGNETEK A5-206-001 |
| Manufacturer |
MAGNETEK |
| Product Type |
AC Drive Module |
| Input Voltage |
200-240V AC, single-phase |
| Output Power |
Up to 5 HP (3.7 kW) |
| Control Protocol |
Modbus RTU, Analog I/O |
| Frequency Range |
0-400 Hz |
| Operating Temperature |
-10°C to +50°C |
| Protection Class |
IP20 (indoor use) |
| Dimensions |
7.5 x 5.5 x 4.2 inches |
| Mounting Method |
Panel-mounted |
| Cooling Type |
Natural convection |
Key Features and Benefits
The MAGNETEK A5-206-001 stands out for its combination of performance and versatility. Its vector control technology enables precise motor speed regulation even under varying loads, ensuring consistent operation in demanding environments. The module’s built-in overload protection and thermal monitoring safeguard against equipment damage, while intuitive diagnostic displays simplify troubleshooting. With plug-and-play functionality, the A5-206-001 reduces installation time, and its modular design allows for easy maintenance or upgrades. Compatibility with common industrial networks—such as Modbus—enables seamless integration with higher-level control systems, making it suitable for both standalone setups and complex automation ecosystems. The drive’s energy-efficient design helps reduce operational costs, while its rugged construction ensures long-term reliability in harsh industrial settings. Whether used in food processing, automotive manufacturing, or material handling, the A5-206-001 delivers the precision and durability needed to optimize production processes.
Related Models
- MAGNETEK A5-204-001 – Lower-power variant (2 HP) for smaller motor applications.
- MAGNETEK A5-406-001 – Three-phase input version with similar power rating.
- MAGNETEK A5-206-002 – Enhanced model with additional I/O ports for expanded connectivity.
- MAGNETEK GPD503 – Previous-generation drive with basic control features.
- MAGNETEK A5-210-001 – Higher-power model (10 HP) for heavy-duty machinery.
- MAGNETEK A5-206-001-E – Economy version with simplified programming options.
