The MVME761-001 MOTOROLA Transition module is an industry-standard connector for these interfaces
The MVME761-0x1 Transition module provides interfaces between the MVME260x, MVME270x, MVME360x, and MVME460x single-board computer VMEmodule and various peripheral devices. The module offers industry standard connectors to simplify customer cable requirements for serial ports, printers, and Ethernet signals.
peculiarity
The features of the MVME761-0x1 transition module include:
[Industry standard connectors for these interfaces]
- 2 EIA-574 asynchronous Serial ports (DTE)
- Two asynchronous/synchronous serial ports with EIA-232-D, EIA-530, V.35, or X.21 interfaces (DCE or DTE)
One parallel port (IEEE standard 1284-I)
- 10Base-T/100Base-TX Ethernet
Features:
Two EIA-574 Asynchronous Serial Ports (DTE)
Two configurable serial ports for EIA-232-D, EIA-530, V.35, or X.21 interfaces
One IEEE standard 1284-I compliant parallel port
10Base-T/100Base-TX Ethernet
Two 60-pin serial interface module (SIM) connectors
The MVME761-0x1 Transition Module provides interfaces between the MVME260x, MVME270x, MVME360x, or MVME460x single-board computer VMEmodule and various peripheral devices. The module offers industry-standard connectors to simplify customer cable requirements for serial ports, printers, and Ethernet signals.
