Model: IC200CPU005
trait
Supports up to 64 modules and up to 2048 L0 points
The west tube er can be automatically inserted by the programmer
Use configuration times 4
64KB of configurable memory for applications,m
Hardware configuration,g register (%R), analog input (%AI).
Model: IC200CPU005
trait
Supports up to 64 modules and up to 2048 L0 points
The west tube er can be automatically inserted by the programmer
Use configuration times 4
64KB of configurable memory for applications,m
Hardware configuration,g register (%R), analog input (%AI).
And analog output (%AQ)
Compilation of charts and finger tables
Nonvolatile flash memory stored by a subroutine
Battery backup with subroutines, data and daytime clock time
Supercapacitors provide energy for memory for one hour.
cku backup battery protects memory contents for more than 1 hour. p
By 6 months s.
When the spare battery is not in use, the shelf life is 5 years.se.
Run/stop switch
Floating point real teaching according to Alou female
Support EZ program storage device (LC200ACC003)
On DLN rail: 70 mm height when power is installed
IC200CPU005 Operation Precautions/Restrictions
1. Using an older version of the non-intelligent analog module in the extension rack will result in a mismatch error in the logging system configuration. Before scanning a failed module, the module must be replaced with a newer revision. The permitted revisions are detailed under Compatibility in the Product Information section above.
2.IC200CPU005 If the integral term is used in the IND or ISA PID loop, avoid PID integral value less than 0.002. The following example illustrates the behavior when using an integer value less than 0.002:
Suppose SP=16000, PV=16000, CV=16000, P=1.00, 1=1.000. D = 0.00
If the integer item is reduced to 0.002; CV invariance
If the integral term is 0.001,CV is reduced to half of its original value (8000)
If the integer is 0.000, CV drops to 0. At this point, there is no point contribution.
3. If the receiver in a single local rack is turned off while the CPU is powered on, the CPU may record an incorrect "rack Add" fault. It is recommended that both the CPU and the receiver be powered by one power supply.
4. Occasionally, after power cycling to the main or extension rack, a "backplane communication failure" may be recorded on the smart Vo module. This is a diagnostic fault that can be eliminated.
5. In very rare cases, when a magnetic field power is lost on a module. Non-intelligent modules in the same rack may also report failure.
6. In very rare cases, IC200CPU005 hot-inserted modules may not be added by the CPU. It will not produce a "module add" error and will not be scanned. This can be corrected by extracting and reinserting the module.
7. In very rare cases, a hot-insert module may cause an analog module in the same rack to set the output to zero. Apart from that, "the module is missing
