IC670MDL240J | IC670MDL240K | 16-point discrete input module
Model: IC670MDL240J
Category: 16-point discrete input module
Finish: New/not new
Warranty: One year
Operating temperature: 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit)
Serial port: RS-485 (via power supply)
CPU Type: single-socket CPU module
User memory: 32 KB
Processor type: 80386EX
Power requirements: 670 MA, from +5 VDC power supply
Typical scan rate: 0.22 milliseconds per 1K logic (Boolean contacts)
Memory storage type: RAM and flash
Rated voltage: 120vac
Input voltage range: 0±132 VAC(47±63 Hz)
User input current: 15 mA per point @ 120 VAC
index
One LED per point shows the status of a single point
PWR LED indicates power supply on the backplane
Isolation: user input logic;
The IC670MDL240 is a 16-point discrete input module in the GE Fanuc field control family. The module has 16 input channels that accept an input signal voltage of 120 VAC in a signal range of 0-132 VAC, 47-63 Hz, and a user input current of 15 mA at each point. The module draws 77mA of current from the Bus Interface Unit (BIU) power supply.
