IC670MDL241J | IC670MDL644 | Input module Model: IC670MDL241J
Category: Input module
Finish: New/not new
Warranty: One year
Input quantity: 16
Voltage type: AC
Frequency 47 to 63 Hertz
The GE Fanuc IC670MDL241J input module is a discrete input module in the Field Control product family. Ac voltage module, rated at 240v AC, 16 input points isolated into 2 groups. Each of these isolated input groups requires power from an external AC power supply (1 external power supply per group, 2 external power supplies in total), while the module itself receives power from its installed bus interface unit or BIU. The inputs on the IC670MDL241J module will respond to 0 to 265 volts AC voltage levels from 47 to 63 Hertz. Not only does the BIU power the entire module, it can also provide intelligent processing functions for the module, such as input configuration. The module can also receive intelligent processing from elsewhere in the system.
GE Fanuc Field Control The IC670MDL241J input module operates in a capacitor and resistor system and provides input filtering to the module by establishing the input threshold required to provide filtering. The complete system also includes optical isolators that provide isolation between logical components and field inputs in the module, and a data buffer that stores data from all 16 module inputs. Each input has an on and off response time rating of 20 milliseconds. The IC670MDL241J input module is rated from 4 to 10 MA for on-going current and from 0 to 1.5 Ma for off-going current.
