IC693CPU350 | IC695CPU315 | Single-socket CPU module

Model: IC693CPU350
Category: Single-socket CPU module
Finish: New, not new
Warranty: One year
Brand: GE

Power requirements: 670 MA, from +5 VDC power supply
Typical scan rate: 0.22 milliseconds per 1K logic (Boolean contacts)
Memory storage type: RAM and flash
Number of Ethernet ports: N/A
Storage temperature: -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit)
Product type: CPU module
Compatibility: GE Fanuc 90-30 PLCs
Clock speed: 25 MHZ
Current input: 670 MA
Voltage input: 5 volts DC
The IC693CPU350 is a GE Fanuc series 90-30 controller. The controller is part of a modular control system with a single-slot wide module capable of controlling up to eight (8) backboards, including the local backboard on which the CPU is mounted.

The IC693CPU350 is designed with 32K bytes of non-configurable user memory. Up to 2048 discrete inputs, 2048 discrete outputs, 2048 analog input words and 512 analog output words. This I/O count density makes the controller suitable for installation in medium to large applications.

The IC693CPU350 does not have a communication port. The controller utilizes a communication port installed in the power supply with an RS485 communication interface that allows connection to programming workstations, handheld programmers (HHP), and devices capable of exchanging data over the RS485 communication standard. This port supports the SNP/SNP-X slave protocol.

The IC693CPU350 is configured with various options. This can be configured using LogicMaster90, Control, VersaPro, and CIMPLICITY Machine Edition Logic Developer application software applications. In addition, a traditional handheld programmer (HHP) can be used to write programs to this controller.
