The GE Fanuc IC693CPU363LT is a 90-30 series processor module. The module is a CPU 363 module with a single slot width, a processor speed of 25 MHz, and a typical scan rate of 0.22 milliseconds per 1K logic for Boolean contacts. It has 240KB of embedded user memory, embedded two (2) serial communication ports, and supports RS232 and RS485 communication standards.
Operating temperature 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit)
The number of Ethernet ports is not applicable
Memory Storage types RAM and flash
Typical scan rate 0.22 ms per 1K logic (Boolean contacts)
Serial port RS-485 (via power supply
Power requirements 890 amps, +5 VDC power supply
Register memory 240 kilobytes
CPU Type Single-socket CPU module
The IC693CPU363LTis equipped with an 80386EX processor with a clock speed of 25 MHz and a typical sweep rate of 0.22 ms per 1K logic for Boolean contacts. The controller's embedded memory is 240KB, internally partitioned to accommodate different registers and internal functions. It has two (2) serial ports, one (1) port with an RJ45 physical interface, while the other port has a 15-pin sub-D connector, both supporting RS232 and RS485 communication standards. It also has a third level RS485 port located on the power supply. All of these ports allow you to download and upload user programs, perform debugging tasks, and fine-tune programs. These ports operate independently and can be configured to operate simultaneously to accommodate other data exchange functions, such as communication with visual components. Other communication protocols supported by IC693CPU363 include Ethernet, FIP, Profibus, GBC, GCM, and GCM+ option modules.
