IC693MDL740H Positive logic output module Power output terminal

Model: IC693MDL740H

Product description: positive logic output module

ON Response time: Maximum 2 ms

Output voltage drop: 1 V Max

Surge current 4.78 amperes, : 10 ms

Output current per common: 2 amps 10 ms

Output current per channel: 0.5 amp

Nooooo. Number of channels per group: eight (8) channels

The IC693MDL740H has a rated voltage of 12/24 volts DC and an operating voltage range of 12 to 24 volts DC (+20%, -15%). The module's output features include 4.78 amps of inrush current (lasting 10 ms), maximum output voltage drop of 1 VDC, OFF state leakage current of 1 mA, on response time of 2 ms, and maximum and off response time of 2 ms. The power consumption of the module is 110 mA (with all outputs turned on) from the 5 V bus on the backplane.

The IC693MDL740H module is a 12 to 24 V DC rated positive logic output module. There are 16 output points, divided into 2 groups, each group of 8, each group has a common power output terminal. The IC693MDL740H module has positive logic characteristics and can be used as the current source of the user's common power bus and positive power bus load. The output device is connected between the negative power bus and the module output. The IC693MDL740H module is compatible with a variety of load devices, including solenoid valves and motor starters. The module has an output voltage range of 12 to 24 V DC. The maximum output current is 0.5 amps per module point and 2 amps per common point. The maximum startup and shutdown response time is 2 milliseconds. The rated surge current for a duration of 10 milliseconds is 4.78 amps.
