Model: IC695CRU320-BB
Installation method: Installation in control room
LD instruction processor: hard PLC
I/O count: 3
Features:
Working voltage: 24V
Output frequency: 10/100 Mbps
Processing speed: 50MHz
Program capacity: 16MB
Data capacity: 256MB
Product certification: CE
Ambient temperature: 0 to 60 degrees Celsius
Ambient humidity: 5 to 95%, non-condensing
Processing customization: No
Weight: 0.2 kg
Origin: Sweden
Overall dimensions: 114 mm *257 mm *80 mm
The IC695CRU320-BB is particularly suitable for redundant or hot standby configurations. With this controller configuration, availability is significantly improved. Two (2) controller racks, configured to function similarly to the primary (active) and secondary (standby) racks. When a single IC695CRU320-BB rack fails, mainly due to an error detected by the IC695CRU320 or an error by the IC695CRU320 processor itself, active controller responsibilities are automatically transferred to auxiliary (standby). The auxiliary rack becomes the host rack, and the faulty rack is moved to the auxiliary rack. In addition, it can be switched manually.
Controller switching is performed in a maximum of one logical scan with a minimum switching time of 3.133 ms. The IC695CRU320-BB supports synchronous links up to IC695RMX128/228 and is capable of transmitting up to 2MB of data. With a Celeron M processor with 1GHz processing speed and 64MB of user memory, the IC695CRU320-BB controller is ideal for large, complex applications with higher critical levels. In addition, up to 512 program blocks can be saved to this processor, with each block size potentially up to 128 KB.
