IC697MDL740 | IC697ALG320 | discrete output moduleSeries :90-70 series
Part number :IC697MDL740
Rated voltage: DC 24 ~ 48v
Output current: 2 amps per point, 4 amps per group
Output voltage range: DC 20 ~ 60v
Required current :0.15 amp
Output quantity :16
Isolation voltage :1500 volts
Surge current :20 amps (Max.)20 ms
Response time :2 ms (Max)
Response pause :2 ms (Max)
Output voltage drop: 0.8V / 0.4ohm (Max)
The Ic697mdl750 is a 90-70 series discrete output module. The module was previously manufactured by GE Fanuc and is now being acquired by Emerson Automation. It has sixteen (16) discrete output channels divided into four (4) groups of eight (8) channels each. Each channel can be configured to provide a 20/60 VDC output voltage range with an output current of 0.5 amps per point and 2 amps per group. When it has a 0.25a current consumption.
The IC697MDL740 discrete output module is an independent module with multiple output channels that can output various types of control signals, such as switching signals, pulse signals or analog signals. These signals are widely used to control machinery, actuators or other related equipment to achieve industrial automation control purposes.
2. Characteristics and advantages
Independence: The design of the IC697MDL740 discrete output module makes each module relatively independent from each other, which is easy to troubleshoot and maintain.
Flexibility: By combining different input/output modules, the system can be flexibly configured to meet different application requirements.
Reliability: The IC697MDL740 vertical design reduces the mutual interference between modules and improves the overall reliability of the system.
Hot insertion function: Some discrete output modules have a hot insertion function that allows users to easily install or replace modules without interrupting operation and without changing field wiring.
