IS200DAMAG1BBB | IS200DAMEG1ABA | Circuit Board |

Model: IS200DAMAG1BBB
Category: Circuit Board
Finish: new, not new,
Stock: Yes
Brand: GE
Size: 17.71 × 13.77 × 7.87 cm
Operating temperature: -30 to 65 degrees Celsius
Series: Mark VIe
Product description


The IS200DAMAG1BBB is a circuit board component in the Mark VI Innovation series of circuit boards for turbine control systems. The Mark VI was one of the last Speedtronic systems created and distributed by GE for turbine control.
The IS200DAMAG1BBB is used as a gate driver amplifier and interface. The board is used as an interface between power switchgear such as IGBTs and the control rack. The board uses 620 frame drive power.


The IS200DAMAG1BBB amplifier gate drives the current of the final stage. Typically, three of these boards are used for each drive. The board consists of four leds, two of which are yellow to indicate when the upper and lower IGBTs are on and two of which are green to indicate when the upper and lower IGBTs are off. The board also includes connectors for gate signals, common signals, and collector signals.


The IS200DAMAG1BBB board is considered to be electrostatic sensitive. In order to avoid damage caused by static buildup, the person handling this component should use electrostatic sensitive processing techniques. This includes using a wristband and ensuring that the device has been removed from the powered device before touching it. AX Control ships this board using an anti-static bag to comply with these operating guidelines. If you are going to store this component for any time, we recommend that you use the bag as part of the storage.
