The IS200EPSMG2A is an integral part of the GE EX2100 series excitation turbine control system. It acts as a power supply module, converting the input voltage into the various output voltages required for the operation of the system. The module is designed for the regulator control part of the EX2100 system.
Main features and components
Part of the EX2100 family: Integrated into a broader GE excited turbine control system.
Exciter power supply: Converts the input voltage to the necessary output voltage.
EPSMG2 Category: Belongs to Group 2 modules for voltage regulator control.
IS200EPSDG_A subboard: Integrates the excitation regulator power supply subboard to enhance performance.
Step-down regulators and push-pull inverters: core components for voltage conversion.
Isolation transformer: Ensures safety and prevents voltage fluctuations.
Frequently Asked questions about IS200EPSMG2A
What is the power feed to the IS200EPSMG2A board?
The power supply fed to the IS200EPSMG2A board is 125 VDC of the EPDM model.
Is there a difference between IS200EPSMG2A and IS200EPSMG1A models?
According to the GEH-6632 EX2100 Excitation Control User Guide, there is no difference between the IS200EPSMG2A and IS200EPSMG1A models.
What is the location of the IS200EPSMG2A model?
The IS200EPSMG2A model is located in the power module under the control rack in the control cabinet.
