IS200TBCIS2CCD | IS200TREGH1BDB | Terminal
Model: IS200TBCIS2CCD
Category: Terminal
Finish: New, not new
Stock: Yes
Warranty: One year
Brand: GE
Product parameters:
- Model :IS200TBCIH2CAA
- Input voltage :24V DC
- Output voltage :5V DC
- Operating temperature :-40 ° C to 85 ° C
- Overall dimensions :100mm × 50mm × 30mm
The IS200TBCIS2CCD interfaces with VTCC/VCRC or PDIA I/O packages depending on the system it is used on. The board accepts 24 dry contact inputs. They are connected to the terminals of the circuit board. Each has 12 obstacles. The board has a nominal 125 VDC floating excitation voltage. Range from 100 to 145 Vdc.
The IS200TBCIS2CCD has three D-shell connectors. These allow the connection of cable connectors. Connectors are 37-pin connectors with locking fasteners.
Terminal blocks on IS200TBCIS2CCDs typically use #12 AWG cables per connection point. When maintenance is required, the terminal block of the circuit board can be removed from the circuit board.
For more information about the features of the IS200TBCIS2CCD, please refer to the General Electric manual or user Guide. These publications will also provide detailed information on installation, maintenance and proper safety procedures. Only trained technicians can operate, maintain, or install Mark VI devices.
