Brand: GE
Model: IS200TREAH2ACC
Product Type: Emergency trip terminal board
Payment method: Wire transfer, Western Union
Port of shipment for remittance: Xiamen, China
Delivery time: 1-3 working days
Condition: New and 100% original
Warranty: 12 months
The IS200TREAH2ACC is an emergency trip terminal board developed by GE. It is part of the Mark VIe control system. The TREAH1A terminal board is an integral component of the Mark* VIe system and is specifically designed for seamless integration with the PPRO Turbine I/O set. The board's inputs and outputs satisfy a variety of functions that are critical to turbine operation and safety.
The IS200TREAH2ACC terminal board has a comprehensive input and output range to ensure efficient operation and control:Customer input terminals: These inputs are facilitated by two 24-point pluggable barrier terminals, providing an organized and accessible interface for customer-specific inputs.
Nine passive pulse rate devices: These devices are distributed in the X/Y/Z section, three in each section, and are responsible for sensing the gears, thus enabling accurate measurement of turbine speed.
Jumper blocks for signal flapping: The IS200TREAH2ACC jumper blocks play a key role in enabling a set of three-speed inputs to flap to all three PPRO I/O packets, optimizing signal distribution for uniform functionality.
125 V DC TMR Voting Output contacts: These output contacts, labeled H2A and H4A, are key components for system trip activation, ensuring fail-safe measures in the event of an emergency.
Voltage Detection circuits: IS200TREAH2ACC Four circuits from 24 to 125 V DC are designed to monitor trip strings and improve system safety and reliability by continuously monitoring voltage levels.
Child board connectors: The inclusion of child board connectors allows for optional feature extensions, providing scalability and customization possibilities for additional or enhanced features.
