Model: PP875H
Item number: 3BSE092983R1
Category: Touch panel
Finish: New, not new
Warranty: One year
Brand: ABB
Environment and certification
dimension
Weight 0.8 kg
Dimensions W x H x D (mm) 204 x 143 x 50 mm
Hole size W x H (mm) 189 x 128 mm
Installation depth mm. (including clearance) 43 (143) mm
Mounting panel mount, VESA 75 x 75
The touchscreen panel features gorgeous TFT/LED display colors and multi-protocol connectivity. The Panel 800 Black series includes PP875M, PP875H and PP886M, which are easy to use Hmis with comprehensive and integrated templates and libraries for every possible process you need. All black panels feature high-resolution graphics and TFT/LED displays. Most models offer widescreen, high-resolution displays for increased efficiency and excellent operator interaction.
Characteristics and advantages
Easy to use
A fully deployable human-machine interface with comprehensive and integrated templates and libraries for every possible process. The Panel Builder tool features the familiar Microsoft® Windows® environment and multiple language support for fast, simple, and efficient engineering.
State-of-the-art graphics
Vector-based high resolution graphics with TFL/LED display with icon-based interface, navigation and control.
Solid and reliable
The Panel 800 is made with a robust and lightweight die-cast powder-coated aluminum housing. The front housing can withstand wet, dusty and harsh environments. The operating temperature ranges from -10° C to + 60° C with a maximum humidity of 85%.
A truly open platform
These panels are built on the open architecture and technology that comes with the.NET framework, enabling multi-brand controller connectivity. There are a variety of connection options available for local communication, extension, remote access, and more.
Digital output
2 x DO solid state relay, 0.5A@24VDC.
