Regarding this product, it has the following features and functions:
Powerful input capability: As an input module of programmable logic controller (PLC), 52030C10-PCD2 can receive various types of input signals, such as DC current, DC voltage, thermal resistance, thermocouple, etc., so that users can select and configure according to actual needs to meet different application scenarios.
High reliability: This module uses advanced technology to ensure high reliability and stability, and can guarantee trouble-free operation for a long time. This is especially important in complex industrial environments that require continuous and stable operation.
Security Standards and Encryption capabilities: The 52030C10-PCD2 supports the Device Identity Composition Engine (DISES) security standard, providing an easy way to increase the underlying security of embedded products. It provides a development kit that gives designers everything they need to incorporate security standards into their products. This safety feature gives the module a significant advantage in applications that require a high degree of security, such as the military and aerospace sectors.
Fast access and clear display: The module enables quick and easy access to detailed information about running process calculations without adding trace files or running a debugger. At the same time, it can also clearly and accurately display the various states of the factory, so that users can timely understand the production situation, and quickly respond to possible problems.
The voltage input signals are connected directly to the 10-pole terminal block (E0 … E7 and COM). To minimize the amount of
interference coupled into the module via the transmission lines, connection should be made according to the principle explained below.
This module can interact with the watchdog, if it is used on base address 240. For details, please refer to the manual “27-600_I/O-modules for PCD1 / PCD2 series and for PCD3” in chapter “A4 Hardware Watchdog”, which describes the correct use of the watchdog together with PCD components.
I/O modules and I/O terminal blocks may only be plugged in and removed when the Saia PCD® and the external +24 V are disconnected from the power supply.
The voltage input signals are connected directly to the 10-pole terminal block (E0 … E7 and COM). To minimize the amount of
