Product Parameters
●Power Rating: 2.3 kW
●Rated Speed: 3000 rpm
●Rated Torque. 7.5 Nm
●Feedback Type: Resolver
●Frame Size. NEMA 56C
●Mounting Type. Flange
●Cooling Method: Fan Cooled
●Insulation Class. Class F
●Encoder Resolution: 2048 PPR
Specifications
●High torque -to-inertia ratio
●High power density
●Low rotor inertia
●High linearity
. Low cogging torque
●Wide speed range
●High overload capability
RELIANCE 57C5522-1 supports a variety of protocol formats, the main one being the Profibus DP protocol. This is a communication protocol widely used in the field of industrial automation, supporting peer-to-peer transmission, data and bus arbitration and other functions, with high speed, long-distance transmission capabilities.
In addition, RELIANCE 57C5522-1 also supports fiber optic transmission with electrical and ground isolation, which helps to reduce interference and improve communication stability and reliability. These features enable RELIANCE 57C5522-1 to operate stably in a variety of industrial environments to meet different communication needs.
The RELIANCE 57C552-1 is a communication and control device with multiple advantages. Here are some of the features of RELIANCE 57C5522-1:
Communication capability: RELIANCE 57C552-1 supports fiber optic transmission and has the ability to transmit long distances at high rates. In addition, it supports the Profibus DP bus with advantages such as peer-to-peer transmission, data and bus arbitration, which helps to improve communication efficiency and stability.
Electrical isolation and ground isolation: The device has the performance of electrical and ground isolation, which can effectively reduce interference and improve the stability of the system.
Industrial grade design: The RELIANCE 57C5522-1 is an industrial grade design with IP30 protection rating, which can adapt to various harsh environments.
Easy installation: Support 35mm DIN rail installation, easy to install on a variety of equipment.
Wide power input: Support DC(9-36)V wide power input, with higher power adaptability.
Alarm output: with relay alarm output, can timely feedback the working status of the equipment.
Redundancy and isolation protection: Supports dual power supply redundancy and isolation protection to improve system stability and reliability.
