PCD2 Suitable for small control platforms Handle multiple communication tasks

Brand :SAIA
Origin: USA
Output frequency :50kHz
Bom number: System card module
Product features: card module
Processing customization: No
Product certification: System card module
Available: nationwide
Import or not: No
Working voltage :220V
Series: System card module
Model :SAIA PCD2.M110
It has four freely assignable input/output module slots and can expand up to 1,024 data points. It has enough processor power and 2 MB of user program memory to ensure it can handle demanding communication tasks with up to 14 interfaces. Operating data is saved by non-volatile FRAM technology to ensure maintenance-free (battery-free) operation.
Modular design; 8/16 sockets for digital/analog, counting, measurement, motion control and other modules
More than 255 local input/output or 2048 remote input/output
An additional 1 MByte memory store programs and data, and an additional 1 MByte flash memory store programs
More than 6 Serial ports RS 232, RS 422, RS 485 or TTY/current loop 20 mA
Field bus Profibus FMS, Profibus DP master/slave, LONWorks, Ethernet-TCP/IP
High speed count interrupt
Software and communicationsPG5's efficient programming capabilities, multi-language capabilities (IL, FUPLA, GRAFTEC) and a large number of accessory tools, complete instruction set, various application libraries, and IEC 1131-3 structure simplify programming and increase program openness and portability.
Coordinated internal resources and the built-in Saia S-Bus enable programs to be transmitted over the network
I/O signals are directly addressed without mirroring, reducing response time
Flexible network integration, communication and programming via Ethernet-TCP/IP, Profibus DP/FMS, LONWorks
PCD2.M127, M157, M177 and M487 can be programmed with Siemens Step7
