The PXle-5105 high-density PX oscilloscope features eight synchronous sampling channels, providing flexible coupling, impedance, voltage range, and filtering Settings. The Px oscilloscope also features multiple trigger modes, high capacity onboard memory, and an instrument driver that includes data streaming and analysis functions. It is ideal for multichannel applications requiring up to 60 MS /s or 60 MHz analog bandwidth. The PXle-5105 also has advanced Px synchronization and data streaming capabilities.
The PXIE-5105 is a high-density PXI oscilloscope from NI (National Instruments) with high performance, multi-channel and software-defined features. It is primarily used to measure and analyze electronic signals and is particularly suitable for multichannel applications requiring up to 60 MS/s or 60 MHz analog bandwidth. Here are the details about the PXIE-5105:
Multi-channel synchronous sampling: The PXIE-5105 provides eight synchronous sampling channels, which means that it can simultaneously capture and record multiple signals, ensuring timing consistency between data, which is especially important for measurements requiring accurate time correlation.
High vertical resolution: The device has a vertical resolution of 12 bits, which allows the device to perform fine quantification of the input signal, enabling it to capture even smaller signal changes.
High real-time sampling rate: The real-time sampling rate reaches 60 MS/s (millions of samples per second), which makes it possible to accurately capture rapidly changing signals, such as high-frequency signals or short-time events.
Wide bandwidth: With 60 MHz analog bandwidth, it ensures that a wide range of frequency components can be processed, which is very advantageous for the acquisition of broadband signals.
Mass storage: Up to 512 MB of onboard memory means that data can be collected for long periods of time without real-time processing or transmission of data.
Flexible signal Settings: The PXIE-5105 offers flexible coupling, impedance, voltage range, and filter Settings that users can adjust as needed to accommodate different types of signals.
Multiple trigger modes: The oscilloscope also has a variety of trigger modes, users can capture specific signal events according to different trigger conditions, improve the accuracy and precision of measurement.
Advanced PXI Synchronization and data Streaming capabilities: The PXIE-5105 supports advanced PXI synchronization and data streaming capabilities, which help achieve accurate synchronization and data transfer in multi-device systems.
Modularity and scalability: The PXIE-5105 can be used in combination with other PXIe-5105 digitizers for high channel count applications, which provides great flexibility for large test systems or multi-point monitoring projects.
Instrument Driver and Data Flow: The PXI oscilloscope also includes an instrument driver that supports data flow and data analysis functions, making it easier for users to process and analyze the acquired data.
Overall, the PXIE-5105 is a feature-rich, high-performance oscilloscope suitable for a variety of applications requiring accurate measurement and analysis of electronic signals
