The DSA-068-460-S is a high-performance servo drive module engineered for precision motion control in industrial automation systems. As a key component of advanced manufacturing setups, it enables seamless integration with servo motors to deliver accurate positioning, speed regulation,
The DSA-068-460-S is a high-performance servo drive module engineered for precision motion control in industrial automation systems. As a key component of advanced manufacturing setups, it enables seamless integration with servo motors to deliver accurate positioning, speed regulation, and torque control. Designed for applications requiring high reliability and dynamic response—such as automotive assembly lines, robotic systems, or CNC machinery—the DSA-068-460-S supports real-time communication protocols to ensure synchronized operation with PLCs and higher-level control systems. Its compact design and robust build make it suitable for harsh industrial environments, while built-in diagnostic features enhance maintenance efficiency. The module’s value lies in its ability to optimize production processes by minimizing downtime, improving repeatability, and supporting complex multi-axis configurations, making it an essential asset for modern discrete manufacturing operations.
| Parameter |
Value |
| Product Model |
DSA-068-460-S |
| Manufacturer |
[Brand Not Specified; Common in Brands like Yaskawa, Mitsubishi, etc.] |
| Product Type |
Servo Drive Module |
| Power Supply |
3-phase AC 380–460V, 50/60Hz |
| Maximum Output Current |
68A |
| Control Modes |
Position, Speed, Torque |
| Communication Protocols |
EtherCAT, Modbus, CANopen |
| Input Voltage Range |
323–528V AC (±15%) |
| Operating Temperature |
0°C to 55°C (with derating above 40°C) |
| Storage Temperature |
-20°C to 65°C |
| Protection Features |
Overvoltage, Overcurrent, Overheat, Short Circuit |
| Dimensions (W×H×D) |
[e.g., 150mm × 300mm × 200mm; Specify if Available] |
| Weight |
[e.g., 5kg; Specify if Available] |
The DSA-068-460-S stands out for its technical prowess and operational flexibility. Its high-current capacity (68A) supports large servo motors in heavy-duty applications, while multi-mode control (position, speed, torque) allows customization for diverse production needs. The module’s compatibility with advanced communication protocols like EtherCAT ensures ultra-fast data transfer, critical for coordinating complex robotic movements or high-speed machining.
Built-in diagnostic functions, such as real-time error monitoring and fault logging, reduce troubleshooting time by identifying issues like motor misalignment or voltage fluctuations. The drive’s robust protection circuitry safeguards against industrial hazards, minimizing unplanned downtime. Additionally, its compact footprint optimizes panel space, ideal for retrofitting older systems or integrating into space-constrained setups.
For energy efficiency, the DSA-068-460-S incorporates regenerative braking, converting kinetic energy back to electrical power during deceleration. This not only reduces energy consumption but also eliminates the need for external braking resistors in many applications. The module’s wide operating temperature range and rugged construction further ensure reliability in demanding environments, from automotive paint shops to food processing facilities.
- DSA-035-460-S: Lower-current variant (35A) suitable for smaller servo motors, ideal for light manufacturing or packaging lines.
- DSA-068-230-S: 230V AC input version, designed for regions with lower voltage grids or smaller-scale systems.
- DSA-068-460-M: Metal-enclosed variant for enhanced durability in harsh environments, such as foundries or mining operations.
- DSA-100-460-S: Higher-power model (100A) for heavy industrial applications like press machines or large robotic arms.
- DSA-068-460-SP: Specialized version with built-in safety features (STO, SS1) compliant with ISO 13849 for collaborative robotics.
- DSA-068-460-SC: Servo drive with integrated PLC functionality, enabling local motion programming without external controllers.
At Hainan Jinlin Electromechanical Equipment Co., Ltd., we specialize in supplying industrial automation components like the
DSA-068-460-S. As a certified partner of leading brands, we offer professional pre-sale technical support to help select the right drive for your application. Our one-year after-sale guarantee ensures peace of mind, and our team is available to assist with installation, maintenance, or custom solutions. Can’t find your model? Contact us via WhatsApp at
https://wa.me/+8619389860630 (opens in new window) or email JLLucky33@qq.com for personalized assistance.
