The PMC5-3X is a high-performance programmable automation controller (PAC) engineered by Mitsubishi Electric for industrial automation applications. As part of the PMC5 series, this compact yet powerful controller combines the flexibility of a PLC with advanced computing capabilities, making it ideal for complex control tasks in manufacturing, energy, and process industries.
The
PMC5-3X is a high-performance programmable automation controller (PAC) engineered by Mitsubishi Electric for industrial automation applications. As part of the PMC5 series, this compact yet powerful controller combines the flexibility of a PLC with advanced computing capabilities, making it ideal for complex control tasks in manufacturing, energy, and process industries. Designed to integrate seamlessly with Mitsubishi’s iQ Platform, the
PMC5-3X excels at real-time monitoring, motion control, and data processing, enabling precise automation across diverse systems. Its modular architecture allows for scalable configurations, while built-in communication ports support Ethernet/IP, Modbus TCP, and Profibus-DP, ensuring compatibility with existing infrastructure. What sets the
PMC5-3X apart is its ability to handle high-speed I/O processing and complex algorithms, delivering reliable performance in mission-critical environments. Whether deployed in automotive assembly lines, power generation plants, or pharmaceutical manufacturing, this controller enhances operational efficiency, reduces downtime, and future-proofs automation investments.
| Parameter |
Value |
| Product Model |
PMC5-3X |
| Manufacturer |
Mitsubishi Electric |
| Product Type |
Programmable Automation Controller (PAC) |
| CPU |
Multi-core processor (up to 2.4 GHz) |
| Memory |
4 GB RAM, 32 GB Flash |
| I/O Points |
Up to 1,024 digital I/O, 512 analog I/O |
| Communication Ports |
3x Ethernet, 2x USB, 2x Serial (RS-232/422/485) |
| Protocol Support |
Ethernet/IP, Modbus TCP, Profibus-DP, MELSECnet/H, CC-Link IE Field |
| Program Languages |
IEC 61131-3 (LD, FBD, ST, IL, SFC) |
| Processing Speed |
0.025 μs/step (basic instructions) |
| Operating Temperature |
-10°C to 60°C |
| Storage Temperature |
-25°C to 70°C |
| Humidity |
5-95% RH (non-condensing) |
| Dimensions |
175 mm x 100 mm x 125 mm |
| Weight |
1.2 kg |
| Power Supply |
24 VDC (19.2-28.8 VDC) |
| Power Consumption |
25 W max |
The PMC5-3X delivers exceptional performance and reliability through its advanced features. Its multi-core CPU enables parallel processing of control tasks, reducing cycle times and improving response rates for time-sensitive applications. This makes it suitable for high-speed motion control systems, such as robotics and conveyor lines, where precision and timing are critical.
Built-in safety functions, compliant with IEC 61508 SIL 3 and ISO 13849-1 PL e standards, ensure fail-safe operation in hazardous environments. The controller’s redundant power inputs and hot-swappable modules minimize downtime, while real-time diagnostic tools provide proactive monitoring of system health. This predictive maintenance capability reduces unplanned outages and extends equipment lifespan.
The PMC5-3X simplifies integration with legacy systems and modern IoT platforms. Its support for multiple industrial protocols allows seamless communication with sensors, actuators, and HMIs from various manufacturers. Additionally, the controller’s built-in web server enables remote access and monitoring via standard browsers, enhancing operational visibility and facilitating rapid decision-making.
For data-driven applications, the PMC5-3X offers robust analytics capabilities. It can collect, process, and transmit large volumes of production data to cloud-based platforms or enterprise systems, enabling predictive analytics and optimization. This data-centric approach improves overall equipment effectiveness (OEE) and streamlines production workflows.
- PMC5-1X: A 入门级 variant with reduced I/O capacity and processing power, ideal for smaller-scale automation projects.
- PMC5-5X: A high-end model with enhanced memory and communication capabilities, designed for large-scale, complex control systems.
- FX5U-32MR/ES-A: A compact PLC from Mitsubishi’s FX5 series, often used alongside the PMC5-3X for distributed control tasks in modular systems.
- Q173DCPU: A motion control CPU module compatible with the PMC5-3X, enabling synchronized control of multiple axes in robotic applications.
- GT2512-VTBD: A Mitsubishi HMI panel that pairs with the PMC5-3X to provide intuitive operator interfaces for monitoring and control.
Hainan Jinlin Electromechanical Equipment Co., Ltd. is a certified partner of Mitsubishi Electric, specializing in industrial automation solutions. We provide comprehensive pre-sale consultation to help clients select the optimal configuration for their
PMC5-3X systems, ensuring seamless integration and performance. Our one-year after-sales guarantee covers technical support, repairs, and replacements, minimizing operational risks. For inquiries or custom solutions, contact us via WhatsApp at
https://wa.me/+8619389860630 (new window opens) or email JLLucky33@qq.com. Trust our expertise to maximize the efficiency of your automation investments.
