The Magnetek 44P01F 3 GPD515C-B011 is a high-performance 3-phase AC drive that plays a crucial role in industrial automation setups. Part of Magnetek's advanced drive series, it is designed to precisely control the speed and performance of motors.
The Magnetek 44P01F 3 GPD515C-B011 is a high-performance 3-phase AC drive that plays a crucial role in industrial automation setups. Part of Magnetek's advanced drive series, it is designed to precisely control the speed and performance of motors. This drive has a core functionality of producing an adjustable voltage and frequency output, which is essential for regulating the operation of squirrel cage induction motors. In an automation system, it serves as a key component for optimizing motor performance, reducing energy consumption, and enhancing overall process efficiency. Its value lies in its ability to provide reliable and flexible motor control, making it suitable for a wide range of industrial applications. The Magnetek 44P01F 3 GPD515C-B011 is engineered to meet the demands of modern industrial environments, ensuring smooth operation and long-term durability.
| Parameter |
Value |
| Product Model |
Magnetek 44P01F 3 GPD515C-B011 |
| Manufacturer |
Magnetek |
| Product Type |
3-phase AC Drive |
| Input Voltage |
AC 3-phase 380 - 460V (50Hz) / 380 - 460V (60Hz) |
| Input Current |
14A |
| Output Voltage |
AC 3-phase 0 - 460V |
| Output Frequency |
0 - 400Hz |
| Output Current |
11.7A |
| Power Rating |
7.5HP |
| Mass |
4.5 kg |
| Control Modes |
V/Hz (2%), Sensorless Vector (0.1%), Flux Vector (0.01% with encoder and card) |
| Current Overload Rating |
150% for 60 seconds |
The Magnetek 44P01F 3 GPD515C-B011 offers several practical strengths. Its Pulse Width Modulation (PWM) design results in low motor noise, creating a more comfortable working environment. With a high starting torque, it can efficiently start motors even under challenging conditions. The drive provides three distinct modes of control, namely V/Hz, sensorless vector, and flux vector control. This flexibility allows it to be tailored to different application requirements. For instance, the V/Hz mode is suitable for general applications, while the sensorless vector mode offers better speed accuracy of 0.1%, and the flux vector control mode, when equipped with a motor - mounted encoder and drive - mounted PG - X2 card, can achieve an impressive 0.01% speed accuracy. It also has a current overload rating of 150% for 60 seconds, which provides protection against sudden load increases. In terms of build quality, it is robustly constructed to withstand the rigors of industrial use, ensuring long - term reliability.
- GPD515C-B007 – A lower power variant with a 5HP rating, suitable for applications where less power is required.
- CIMR - G5M44P0 – An equivalent Yaskawa part number for the same drive, highlighting the collaborative manufacturing relationship.
- GPD515C-B015 – A higher power option with a 10HP rating, designed for applications that demand more robust motor control.
- CIMR - G5U44P0 – Another Yaskawa - branded equivalent, offering the same functionality under a different part number.
- GPD515C-B022 – A more powerful version with a 15HP rating, suitable for heavy - duty industrial applications.
