The YASKAWA CIMR - AU4A0038A AA is a high - performance variable frequency drive that plays a crucial role in industrial automation setups. As part of YASKAWA's advanced A1000 series, it is designed to control the speed and torque of AC motors with great precision.
The YASKAWA CIMR - AU4A0038A AA is a high - performance variable frequency drive that plays a crucial role in industrial automation setups. As part of YASKAWA's advanced A1000 series, it is designed to control the speed and torque of AC motors with great precision. Its core functionality lies in its ability to convert fixed - frequency and fixed - voltage power into adjustable - frequency and adjustable - voltage power for motor operation. This makes it valuable in a wide range of applications, from simple pumps and fans to complex industrial machinery. Whether in a manufacturing plant or a processing facility, the YASKAWA CIMR - AU4A0038A AA ensures smooth and efficient motor control, optimizing energy usage and enhancing overall system performance.
| Parameter |
Value |
| Product Model |
YASKAWA CIMR - AU4A0038A AA |
| Manufacturer |
YASKAWA |
| Product Type |
Variable Frequency Drive |
| Input Voltage |
380 - 480 VAC, 3 - phase (- 15% ~ + 10%) |
| Output Current (Normal Duty) |
38 A |
| Output Current (Heavy Duty) |
31 A |
| Maximum Motor Power (Normal Duty) |
25 hp |
| Maximum Motor Power (Heavy Duty) |
20 hp |
| Output Frequency |
0 - 400 Hz (higher frequencies available with custom software) |
| Control Methods |
V/F, V/F with encoder, open - loop or closed - loop current vector |
| Motor Types |
Asynchronous (IM - induction with squirrel - cage rotor), Synchronous (IPM - internal permanent magnet, SPM - surface permanent magnet, excluding 600 V class) |
| Ambient Temperature |
- 10 °C to + 40 °C (chassis with zero side space or Type 1), - 10 °C to + 50 °C (chassis installation) |
| Protection Degree |
IP20 |
| Global Certification |
CE, CSA, C - tick, RoHS, UL |
The YASKAWA CIMR - AU4A0038A AA offers several practical strengths. Its open - loop or closed - loop vector control provides outstanding regulation, enabling precise torque production and position control capabilities. The continuous auto - tuning feature optimizes performance by compensating for changes in motor temperature, ensuring consistent operation over time. High - frequency injection technology allows for high - precision open - loop control of interior permanent magnet motors, expanding its application scope.
Fast - acting current and voltage limiters are in place to prevent unwanted shutdowns, helping the drive to maintain continuous operation during periods of excessive demand. High - slip braking is another advantage, reducing the need for dynamic braking resistors and thus cutting down installation costs. It also comes with communication options for major industrial networks, facilitating high - speed control and monitoring while reducing installation complexity and cost.
The drive is equipped with DriveWorksEZ PLC, a powerful software development language through functional blocks. There is also a frontal USB port for easy PC connection, and the control board can be replaced without losing configuration parameters. With a one - year after - sale guarantee provided by Hainan Jinlin Electromechanical Equipment Co., Ltd., you can rely on the product's quality and our professional after - sale service.
- CIMR - AU4A0038FAA: A ruggedized variant with a higher temperature range, suitable for more demanding environmental conditions compared to the YASKAWA CIMR - AU4A0038A AA.
- CIMR - AU4A0038UAA: A model with a different enclosure type (flange mount), which may be more suitable for specific installation requirements in industrial settings compared to the standard YASKAWA CIMR - AU4A0038A AA.
- CIMR - AU4A0030A AA: An earlier version with lower power output, having a maximum motor power that is less than the YASKAWA CIMR - AU4A0038A AA, suitable for applications with lower power demands.
- CIMR - AU4A0045A AA: An upgrade with higher power capabilities, providing more power for applications that require greater motor performance compared to the YASKAWA CIMR - AU4A0038A AA.
- CIMR - AU4A0038A AA - EXT: A companion module that can be used in conjunction with the YASKAWA CIMR - AU4A0038A AA to expand its functionality, perhaps adding more input/output options or enhanced communication features.
Hainan Jinlin Electromechanical Equipment Co., Ltd. is a certified partner of industry leaders. We provide comprehensive pre - sale services to help you choose the right product. And with our one - year after - sale guarantee, you can have peace of mind. If you can't find the desired model, please contact us via
