The input is typically provided by JPDP or JPDS with up to three redundant 28V DC input power supplies, which are received through different pins of the 5-pin Mate-n-lok input connector to achieve triple redundancy, respectively marked as red, blue, and black. The remaining two pins of this connector are used to transmit the return current shared by the three TMR power supplies
The output is R, S, and T power supplies
The circuit board measures 29.21 cm in height and 2.54 cm in width
Country of origin: The United States
The input is typically provided by JPDP or JPDS with up to three redundant 28V DC input power supplies, which are received through different pins of the 5-pin Mate-n-lok input connector to achieve triple redundancy, respectively marked as red, blue, and black. The remaining two pins of this connector are used to transmit the return current shared by the three TMR power supplies
The output is R, S, and T power supplies, each equipped with two control power supply I/O component power output connectors
Daisy-chain capability: Multiple of this board can be connected in series with other JPDL boards to efficiently supply power to a row of terminal boards and their related I/O components
The additional connectors are marked as JR1, JR2, JS1, JS2, JT1 and JT2, all of which are 2-pin configurations and are equipped with self-resetting fuses that can withstand up to 2 amperes of current for protection
Circuit type: Isolation control power distribution circuit
The installation direction is vertical
Connector type Mate-n-lok
Key features and advantages
High-efficiency power distribution: It can precisely and efficiently distribute DC power between the control power supply and I/O components, ensuring the stable operation of all parts of the system and reducing the risk of failure caused by power supply issues.
Daisy-chain connection: Supports daisy-chain connection mode, facilitating connection with multiple downstream JPDL boards, simplifying wiring, enhancing system scalability, and allowing for flexible construction of power distribution networks based on actual needs.
Branch circuit protection: For each I/O component connection, a branch circuit protection composed of a positive temperature coefficient fuse device is provided. It responds quickly when the current is abnormal, protecting the equipment from damage and enhancing system reliability.
Hardware redundancy control: It has the function of managing hardware redundancy. When some components of the system fail, it can ensure that key functions continue to operate, reduce downtime, and enhance the overall stability of the system.
Independent power supply circuits: Three independent power supply circuits are on-board, which can achieve structured separation of control power supplies. For example, in a TMR system, independent control power supplies can be provided for R, S, and T hardware respectively, meeting the differentiated power supply requirements of different hardware.
Compact design: It belongs to the small module in the Mark VI series. Compared with other large modules, it is more convenient for installation, maintenance and replacement, reduces the operation difficulty, and saves time and labor costs.
Related model
IS200JPDFG1A: The power distribution-related board card of the same Mark VI system is part of the IS2020JPDF power module. It is composed of a circuit board, a sheet metal structure with a DC circuit breaker, an input filter, a current-limiting resistor and a series diode, and is used to distribute the DC power supply to a large capacity of DC power. It has certain complementarity with IS200JPDLG1A in terms of functions and application scenarios.
IS200JPDLG1ABC: Similar to the IS200JPDLG1A model, there may be minor differences in functions, configurations or versions, specifically in power distribution characteristics, interface forms or certain special functions, to meet the diverse industrial application requirements.
IS200JPDLG1AAC: Also a local DC power distribution board, it shares similarities with IS200JPDLG1A in terms of power output connectors, connection methods with other devices, and application scenarios. However, there are differences in certain technical details or application focuses, such as possible varying adaptability in specific industrial environments.
