The MAGNETEK A5-206-001 is a specialized industrial drive module designed for precision motor control in manufacturing and automation systems. As part of MAGNETEK’s advanced drive solutions, this module is engineered to deliver reliable speed and torque regulation for AC motors, making it ideal for applications requiring high-performance motion control—such as conveyor systems, packaging machinery, or material handling equipment.
The MAGNETEK A5-206-001 is a specialized industrial drive module designed for precision motor control in manufacturing and automation systems. As part of MAGNETEK’s advanced drive solutions, this module is engineered to deliver reliable speed and torque regulation for AC motors, making it ideal for applications requiring high-performance motion control—such as conveyor systems, packaging machinery, or material handling equipment.
The core functionality of the
A5-206-001 revolves around converting incoming AC power to DC and then modulating it to generate variable-frequency AC output for motor control. This allows seamless adjustment of motor speed and acceleration profiles, enhancing system efficiency and reducing mechanical stress. Its value lies in its ability to integrate with existing control networks, providing real-time diagnostics and energy optimization. For instance, in a food processing plant, the module can precisely control conveyor belts to match production rates while minimizing power consumption.
| Parameter |
Value |
| Product Model |
MAGNETEK A5-206-001 |
| Manufacturer |
MAGNETEK |
| Product Type |
AC Drive Module |
| Power Rating |
20 HP (15 kW) |
| Input Voltage |
460V AC, 3-phase, 50/60 Hz |
| Output Voltage |
0–460V AC (variable frequency) |
| Control Method |
Vector control for precise torque and speed regulation |
| Communication Protocols |
Modbus RTU, Ethernet (optional) |
| Operating Temperature |
-10°C to +50°C (with derating above 40°C) |
| Protection Features |
Overvoltage, overcurrent, overtemperature, short-circuit protection |
| Dimensions |
12.5” x 9.8” x 7.2” (318 mm x 249 mm x 183 mm) |
| Weight |
15 lbs (6.8 kg) |
The MAGNETEK A5-206-001 stands out for its combination of performance and adaptability. Its vector control technology enables precise motor operation even at low speeds, ensuring consistent performance in applications like winding machines or robotic arms. The module also supports plug-and-play functionality, simplifying installation and reducing setup time—critical for minimizing production downtime.
Energy efficiency is a core advantage: the drive optimizes power usage by adjusting output based on load requirements, which can lead to up to 30% energy savings in continuous operation. For example, in a fan or pump system, the drive reduces speed during low-demand periods, cutting electricity costs without compromising performance.
The module’s robust design includes reinforced heat sinks and industrial-grade components, making it suitable for harsh environments. Its built-in diagnostics provide real-time status updates on motor health, fault conditions, and energy usage, enabling proactive maintenance. Additionally, the A5-206-001 supports multiple programming interfaces, allowing customization for specific application needs—such as integrating with a plant’s supervisory control and data acquisition (SCADA) system.
- MAGNETEK A5-210-001: 10 HP variant with similar features, ideal for smaller motor applications.
- MAGNETEK A5-230-001: 30 HP model for higher-power systems, compatible with the same control architecture.
- MAGNETEK GPD503: A legacy drive series that the A5-206-001 replaces, offering upgraded efficiency and digital controls.
- MAGNETEK A5-206-002: A variant with enhanced communication options, such as Profinet or EtherNet/IP.
- MAGNETEK A5-206-001-B: A ruggedized version designed for outdoor or high-dust environments, with increased IP protection.
Hainan Jinlin Electromechanical Equipment Co., Ltd. is a certified partner of industry leaders like MAGNETEK, specializing in delivering reliable automation components. Our professional pre-sale services help identify the right solution for your needs, and all products including the
MAGNETEK A5-206-001 come with a 1-year after-sale guarantee. If you can’t find a model or need technical support, contact us via
