The MAGNETEK GPD506V - A080 is a high - performance variable frequency drive designed to precisely control AC motors. It plays a pivotal role in industrial automation setups, especially in applications where motor speed and torque need to be adjusted according to varying operational requirements. As part of MAGNETEK's advanced drive product line, the GPD506V - A080 offers seamless integration into existing industrial systems.
The MAGNETEK GPD506V - A080 is a high - performance variable frequency drive designed to precisely control AC motors. It plays a pivotal role in industrial automation setups, especially in applications where motor speed and torque need to be adjusted according to varying operational requirements. As part of MAGNETEK's advanced drive product line, the GPD506V - A080 offers seamless integration into existing industrial systems. Its core function is to convert fixed - frequency and fixed - voltage power supply (200 - 220V input in this case) into a variable - frequency and variable - voltage output to drive motors. This enables enhanced process control, energy savings, and smooth motor operation. With an 88A capacity, it can handle motors of substantial power, making it valuable for a wide range of industrial applications such as conveyors in manufacturing plants, pumps in water treatment facilities, and fans in ventilation systems. The MAGNETEK GPD506V - A080 stands out for its reliability, compatibility with different motor types, and user - friendly interface, which together contribute to increased productivity and reduced downtime in industrial processes.
| Parameter |
Value |
| Product Model |
MAGNETEK GPD506V - A080 |
| Manufacturer |
MAGNETEK |
| Product Type |
Variable Frequency Drive |
| Power Input |
200 - 220V AC, 50/60Hz |
| Output Current |
88A |
| Output Voltage |
0 - 220V AC (adjustable) |
| Output Frequency |
0 - 400Hz (programmable) |
| Control Method |
Vector control for accurate speed and torque regulation |
| Communication Protocol |
Modbus RTU (for basic communication), optional CANopen or Ethernet |
| Operating Temperature |
-10°C to +50°C |
| Storage Temperature |
-20°C to +60°C |
| Dimensions |
[Provide dimensions if available] |
| Mounting Style |
Panel - mount or DIN - rail mountable |
| Protection Rating |
IP20 (provides protection against dust and limited water ingress) |
| Overload Capacity |
150% of rated current for 60 seconds |
The MAGNETEK GPD506V - A080 offers several distinct features that enhance its performance and value. Its advanced vector control technology ensures precise speed and torque control, allowing motors to start smoothly and operate efficiently under different load conditions. This is crucial for applications where consistent performance is required, such as in precision manufacturing processes.
In terms of energy efficiency, the drive is designed to optimize power consumption. By adjusting the motor speed according to the actual load, it reduces unnecessary energy waste, resulting in lower electricity bills and a smaller environmental footprint. The GPD506V - A080 also comes equipped with comprehensive protection features. Over - voltage, under - voltage, over - current, and thermal overload protection safeguard the drive and the connected motor from potential damage, increasing the overall system's reliability and lifespan.
The user - friendly interface of the
MAGNETEK GPD506V - A080 simplifies installation, commissioning, and day - to - day operation. It allows for easy parameter setting and monitoring of motor performance. Additionally, its compatibility with multiple communication protocols enables seamless integration into larger industrial control systems, such as PLC - based automation setups. This makes it possible to remotely control and monitor the drive, enhancing system flexibility and management capabilities.
- MAGNETEK GPD506V - A008 – A lower - current variant with 8A capacity, suitable for smaller motors in less demanding applications.
- MAGNETEK GPD506V - A054 – Offers a different current rating (54A), designed for motors with medium - power requirements, providing an alternative option for applications where the 88A of the GPD506V - A080 may be excessive.
- MAGNETEK GPD506V - B080 – Similar to the GPD506V - A080 in current capacity but may have different feature sets or targeting specific industries or applications.
- MAGNETEK GPD506V - A100 – A higher - current version with 100A capacity, suitable for driving larger motors in heavy - duty industrial applications.
- MAGNETEK GPD506V - A030 – With a 30A rating, it caters to motors in light - industrial or smaller - scale commercial applications where lower power requirements are the norm.
Hainan Jinlin Electromechanical Equipment Co., Ltd. is a certified partner of industry leaders like Bentley Nevada, Honeywell, and ABB. We specialize in providing top - notch industrial automation components, including the
MAGNETEK GPD506V - A080. Our team offers professional pre - sale technical support to help you choose the right product for your needs. Moreover, we provide a one - year after - sale guarantee for the
MAGNETEK GPD506V - A080, ensuring worry - free operation. Can't find the exact model you need? Contact us via WhatsApp:
https://wa.me/+8619389860630 or email: JLLucky33@qq.com for personalized assistance.
