The Magnetek GPD515C - B014 is a high - performance AC drive that holds a significant place in industrial motor control setups. It is part of the GPD515 series, renowned for its reliability and advanced functionality. This drive is designed to precisely control the speed of squirrel cage induction motors, which are widely used in various industrial applications.
The Magnetek GPD515C - B014 is a high - performance AC drive that holds a significant place in industrial motor control setups. It is part of the GPD515 series, renowned for its reliability and advanced functionality. This drive is designed to precisely control the speed of squirrel cage induction motors, which are widely used in various industrial applications. Its core function is to generate an adjustable voltage and frequency output, enabling smooth and efficient speed regulation. In an automation system, the Magnetek GPD515C - B014 is often a key component for processes that demand accurate motor speed control, such as in conveyor systems, pumps, and fans within manufacturing plants. What makes the Magnetek GPD515C - B014 valuable is its ability to provide high - starting torque, low motor noise, and multiple control modes to suit different application requirements, ensuring optimal performance in diverse industrial scenarios.
| Parameter |
Value |
| Product Model |
Magnetek GPD515C - B014 |
| Manufacturer |
Magnetek |
| Product Type |
AC Drive |
| Rated Input Voltage |
3 - phase, 380 - 460 VAC |
| Rated Input Current |
17.8 A |
| Rated Input Frequency |
50 - 60 Hz |
| Rated Output Voltage |
3 - phase, 0 - 460 VAC |
| Rated Output Power |
10 HP |
| Rated Output Current |
14.8 A |
| Output Frequency Range |
0 - 400 Hz |
| Control Modes |
V/Hz (2% accuracy), Sensorless Vector (0.1% accuracy), Flux Vector control (0.01% accuracy with motor - mounted encoder and drive - mounted PG - X2 card) |
| Current Overload Rating |
150% for 60 seconds |
| Enclosure Type |
NEMA 1 (if applicable, based on reference) |
The Magnetek GPD515C - B014 offers a plethora of features that enhance its performance and usability. One of its standout features is the Pulse Width Modulation (PWM) design. This design not only results in low motor noise, which is crucial in environments where noise reduction is essential, but also provides high starting torque. This high starting torque allows the motor to quickly reach the required operating speed, even when starting under heavy loads, improving the overall productivity of the industrial process.
In terms of control flexibility, the
Magnetek GPD515C - B014 offers three distinct control modes. The V/Hz mode is suitable for general - purpose applications where a basic level of speed control is sufficient. The sensorless vector mode provides a higher level of speed accuracy, making it ideal for applications that require more precise control without the need for an encoder. For the most demanding applications that require extremely accurate speed control, the flux vector control mode (when used with the appropriate encoder and card) offers unrivaled precision.
The drive also excels in handling transient conditions. With automatic stall prevention and voltage boost features, it can avoid nuisance tripping during load or line - side transient events. This ensures continuous operation of the motor, reducing downtime and maintenance costs. Additionally, the
Magnetek GPD515C - B014 does not induce voltage line notching distortion back to the utility line and maintains a high displacement power factor of not less than 0.98 across its entire speed range, contributing to energy - efficient operation and a cleaner power supply.
- Magnetek GPD515C - B007: A lower - power variant of the Magnetek GPD515C - B014, with a rated output power of 7.5 HP, suitable for applications that require less power.
- Magnetek GPD515C - B020: This model has a higher power rating of 20 HP compared to the 10 HP of the Magnetek GPD515C - B014, making it suitable for larger - scale industrial processes that demand more power.
- Magnetek GPD515C - B014 - UL: A version of the Magnetek GPD515C - B014 that has been certified by UL, ensuring compliance with specific safety and quality standards, which may be required in certain regions or industries.
- Magnetek GPD515C - B014 - IP54: Features an IP54 enclosure, providing a higher level of protection against dust and water ingress compared to the standard NEMA 1 enclosure of the Magnetek GPD515C - B014, suitable for use in harsher environmental conditions.
- Magnetek GPD515C - B014 - Plus: An upgraded model with additional communication interfaces, allowing for easier integration with more complex industrial control systems and enabling enhanced remote monitoring and control capabilities.
At Hainan Jinlin Electromechanical Equipment Co., Ltd., as a certified partner of industry leaders, we are committed to providing top - notch service. Our professional pre - sale team is ready to assist you in choosing the right product for your needs. After - sale, we offer a one - year guarantee for the
Magnetek GPD515C - B014, ensuring worry - free operation. If you can't find the desired model or have any questions, please contact us via
