The Magnetek MLTX 2 175 - 13337 - 1000 is a state - of - the - art radio remote control bellybox transmitter. It represents the pinnacle of Magnetek's innovation, integrating the latest electronic technology within a design that emphasizes both functionality and user - friendliness.
The Magnetek MLTX 2 175 - 13337 - 1000 is a state - of - the - art radio remote control bellybox transmitter. It represents the pinnacle of Magnetek's innovation, integrating the latest electronic technology within a design that emphasizes both functionality and user - friendliness. This transmitter is engineered to serve as a reliable control solution across a diverse range of industries, such as tow trucks, cement trucks, boom trucks, truck cranes, concrete mixers, drill rigs, and mining equipment. Its lightweight and comfortably contoured yet durable case makes it an ideal choice for operators who require a tool that can withstand the rigors of heavy - duty usage while providing ease of handling. The Magnetek MLTX 2 175 - 13337 - 1000 offers a plethora of customizable options, enabling it to be tailored precisely to the unique needs of various applications.
| Parameter |
Value |
| Product Model |
Magnetek MLTX 2 175 - 13337 - 1000 |
| Manufacturer |
Magnetek |
| Product Type |
Radio Remote Control Bellybox Transmitter |
| Overall Dimensions |
L 10.15 x W 6.0 x D 5.375 inches |
| Mounting Options |
Side mounted key switch and code plug, mounting hook or magnet mount |
| Enclosure Rating |
NEMA 4 (IP66), explosion - proof enclosure; nylon housing |
| Supply Voltage |
(4) AA batteries (rechargeable NiMH battery pack optional) |
| Radio Frequency |
Several frequency options including 400 MHz, 900 MHz, and 2.4 GHz (synthesized RF or frequency hopping spread spectrum RF) |
| Inputs |
7 single axis JS levers or 2 dual axis joysticks - 12 toggles, mushroom e - stop available (proportional, 1, 2, 3, or 5 speeds in a non - detent lever or joystick) |
| Outputs |
Digital LED's or LCD screen feedback, full programmable screen feedback |
| Diagnostics |
2.0 LCD screen with full system machine feedback, fully programmable |
| Connection |
Can be tethered (rating output dependent), CAN - bus pendant option available (J1939) |
| Operating Temperature Range |
- 40 °C to + 85 °C |
| Storage Temperature Range |
- 40 °C to + 85 °C |
| Environmental Protection |
IP66 |
| Configuration |
Can be configured on a Windows PC with optional radio control programmer (RCP) |
The Magnetek MLTX 2 175 - 13337 - 1000 stands out for its ergonomic design. The contoured case is not only comfortable to hold but also significantly lighter compared to many of its counterparts, being up to 50% lighter. This lightness, combined with the angled lever or joystick controls, enhances operator comfort during extended use. The transmitter's rugged nylon housing is built to withstand shocks, and with its NEMA 4 (IP66) rating, it can operate flawlessly in harsh industrial environments, whether it's dust - filled mines or rain - soaked construction sites.
The synthesized frequency generation technology used in the Magnetek MLTX 2 175 - 13337 - 1000 boosts its reliability, ensuring a stable and consistent signal transmission. An added security feature is the access code system, which provides peace of mind as it ensures that the signal only controls the intended equipment. Power consumption is minimized, resulting in one of the longest - lasting battery lives in the industry, and the option of a rechargeable NiMH battery pack adds to its convenience.
In terms of customization, users can choose up to 7 levers or 3 joysticks, along with up to 12 toggles and a mushroom e - stop. The transmitter also offers stepless, 1, 2, 3, or 5 - speed options in non - detent levers or joysticks, making it adaptable to different operational requirements. The 2.0 LCD screen provides comprehensive system diagnostics, including battery life, signal strength, and warning symbols, allowing for quick and informed decision - making.
- Magnetek MLTX 2 (different frequency variants) - These models have different radio frequency options, such as a version with a more specialized frequency for use in areas with high electromagnetic interference.
- Older Magnetek bellybox transmitters - Previous models that lack the advanced features of the Magnetek MLTX 2 175 - 13337 - 1000, like the less ergonomic design and lower - durability housing.
- Competitor bellybox transmitters with similar functions - While they may offer similar basic control functions, they lack the specific customization options and the high - quality build of the Magnetek MLTX 2 175 - 13337 - 1000.
- Magnetek MLTX 2 with different input/output configurations - Some models may have a different combination of levers, toggles, or feedback mechanisms to suit specific types of equipment.
- Magnetek MLTX 2 with enhanced diagnostic capabilities - These versions have additional diagnostic features, such as more detailed error codes for in - depth system analysis.
