The Xycom 117190-001 Backplane excels in providing a stable and efficient platform for industrial systems. Its 7-slot configuration offers flexibility for system expansion, allowing users to integrate multiple modules while maintaining optimal signal integrity.
Product Overview
The Xycom 117190-001 Backplane is a critical component designed for industrial control systems, specifically engineered to provide a robust and reliable foundation for Xycom's VMEbus-based platforms. As a key element in the VMEbus architecture, this backplane facilitates high-speed data transfer and power distribution among multiple modules, ensuring seamless communication and synchronization in demanding industrial environments. Its role is to mechanically support and electrically connect various circuit boards, such as processors, I/O modules, and communication cards, enabling them to function as a cohesive unit. What sets the 117190-001 apart is its precision engineering, which minimizes signal interference and maximizes system stability, making it ideal for applications requiring high availability, such as manufacturing automation, power generation, and transportation systems.
Technical Specifications
| Parameter |
Value |
| Product Model |
Xycom 117190-001 |
| Manufacturer |
Xycom |
| Product Type |
VMEbus Backplane |
| Bus Standard |
VME64x (compatible with VME) |
| Slot Configuration |
7 slots (1 system slot, 6 peripheral) |
| Signal Integrity |
Low crosstalk, high-speed traces |
| Power Distribution |
+5V, ±12V, +3.3V (adjustable) |
| Cooling Method |
Conduction and forced air |
| Dimensions (LxWxH) |
233.4mm x 160mm x 20mm |
| Weight |
1.2kg |
| Operating Temperature |
-20°C to 60°C |
| Mounting Type |
Rack-mountable with DIN rail support |
| Compliance |
IEEE 1014-1987 (VMEbus standard) |
Key Features and BenefitsThe
Xycom 117190-001 Backplane excels in providing a stable and efficient platform for industrial systems. Its 7-slot configuration offers flexibility for system expansion, allowing users to integrate multiple modules while maintaining optimal signal integrity. The backplane's VME64x compatibility ensures backward compatibility with legacy VME modules while supporting advanced features like higher data transfer rates and enhanced addressing capabilities.
Engineered for reliability, the 117190-001 features redundant power inputs and overcurrent protection, safeguarding against electrical faults and ensuring uninterrupted operation. Its low-impedance power planes minimize voltage drops, even under heavy load conditions, ensuring consistent power delivery to all connected modules. Additionally, the backplane's robust mechanical design resists vibration and shock, making it suitable for harsh industrial environments.
Hainan Jinlin Electromechanical Equipment Co., Ltd., as an authorized Xycom partner, provides comprehensive support for the
117190-001 Backplane. Our pre-sales team assists with system design and compatibility checks, ensuring seamless integration with existing infrastructure. Post-purchase, we offer a one-year warranty and technical support, ensuring prompt resolution of any issues. This commitment to service, combined with the backplane's durability, reduces total cost of ownership and maximizes system uptime.
Related Models
117190-002 – Variant with 9 slots, ideal for larger systems requiring more I/O modules.
117190-003 – Enhanced version with improved EMI shielding for high-noise environments.
117189-001 – 5-slot backplane for compact systems with space constraints.
117191-001 – Backplane with integrated cooling channels for thermal management.
117192-001 – VXIbus-compatible backplane for hybrid VME/VXI systems.
117193-001 – High-density backplane with 13 slots for advanced applications.
