The XYCOM 3100C UNMP is an industrial operator interface panel developed by XYCOM Automation. It serves as a crucial component for interacting with industrial control systems, providing operators with a user - friendly platform to monitor and control various processes.
The XYCOM 3100C UNMP is an industrial operator interface panel developed by XYCOM Automation. It serves as a crucial component for interacting with industrial control systems, providing operators with a user - friendly platform to monitor and control various processes. This device is designed to meet the demands of rugged industrial environments, making it suitable for applications in manufacturing plants, power generation facilities, and other industrial settings where reliable operation is essential.
The
XYCOM 3100C UNMP features a 5.9 - inch diagonal LCD flat - panel display with a resolution of 320x240. This display, protected by an impact - resistant shield, adheres to NEMA 4 / NEMA 12 or IP65 standards, ensuring protection against dust, moisture, and other environmental factors. The front display and keypad panel are sealed, further enhancing its durability in harsh conditions. It comes equipped with a full numeric keypad along with cursor control keys, enabling operators to input commands and navigate through interfaces with ease. Additionally, it has an AT keyboard interface (MicroDIN connector) for added connectivity options.
| Parameter |
Value |
| Product Model |
XYCOM 3100C UNMP |
| Manufacturer |
XYCOM Automation |
| Product Type |
Industrial Operator Interface Panel |
| Display Type |
LCD Flat - Panel |
| Display Size |
5.9 - inch diagonal |
| Display Resolution |
320x240 |
| Protection Standards |
NEMA 4 / NEMA 12, IP65 |
| Keypad Type |
Full numeric with cursor control keys |
| Keyboard Interface |
AT (MicroDIN connector) |
| Communication Ports |
One RS - 232 and one RS - 485 serial port |
| PC Card Interface |
PC card 2.1 (Type I or Type II) |
| Power Supply |
90 - 250V - AC, 47 - 63Hz |
The XYCOM 3100C UNMP offers several key features that enhance its usability and reliability in industrial applications. The large, easy - to - read 5.9 - inch display allows operators to clearly view process information, status indicators, and graphical interfaces. The impact - resistant shield and sealed front panel ensure that the device can withstand accidental knocks, vibrations, and exposure to dust and moisture, reducing the risk of damage and minimizing downtime.
The full - featured keypad and cursor control keys provide a familiar and efficient way for operators to input data, set parameters, and control industrial processes. The RS - 232 and RS - 485 serial ports enable seamless communication with other industrial devices such as PLCs (Programmable Logic Controllers), sensors, and actuators. This connectivity allows for real - time data exchange, ensuring that the operator interface panel can be integrated into complex industrial control systems.
The PC card 2.1 interface (Type I or Type II) offers expandability options. Users can insert memory cards or other compatible PC cards to store additional data, software, or configuration files, enhancing the functionality of the device. The
XYCOM 3100C UNMP is also designed to be powered by a wide - range AC input (90 - 250V - AC, 47 - 63Hz), making it suitable for use in different regions and power supply conditions without the need for additional voltage converters in most cases.
- XYCOM 3100: A related model that might have a different form factor or a more basic set of features compared to the XYCOM 3100C UNMP. It could potentially lack some of the advanced protection features or have a different display resolution.
- XYCOM - specific operator interface panels for different PLC brands: There are likely other XYCOM panels designed to interface more directly with specific brands of PLCs. For example, a panel optimized for use with Siemens PLCs might have pre - configured communication protocols and software interfaces that are more tailored to Siemens' systems, while the XYCOM 3100C UNMP offers more general - purpose connectivity.
- XYCOM panels with larger or smaller displays: Some XYCOM operator interface panels may come with larger displays, say 7 - inch or 10 - inch, for applications where a more detailed view of the process data is required. Conversely, there could be smaller - sized panels, perhaps 4 - inch, for use in space - constrained industrial control panels where the XYCOM 3100C UNMP's 5.9 - inch display might be too large.
-
