Product parameter
Model: 1394C-SJT05-D
Capacity: 8MB
Dimensions: PCMCIA
Interface: ATA
Phone size: 85.6 x 54 x 3.3 mm
Weight: 10 g
Operating temperature: 0 to 60 °C (32 to 140 °F)
Storage temperature: -20 to 85 °C (-4 to 185 °F)
The Allen-Bradley 1394C-AM04 is a multi-axis module belonging to the 1394 Series C series. Its specifications are the same as other multi-axis modules with a peak power of 3 kW. The module has a sustained output current (RMS) of 4.5 amps, but in one second, the peak current can reach 9 amps. The 1394C-AM04 has a nominal input voltage of 530 to 680 V DC, its capacitance is the same as that of the 1394C-AM03, and the rate is 110 microfart. It weighs 5 kilograms and has a radiator in the cabinet.
The 1394C-SJT05-D has a sliding lock function that allows easy wiring modification. Be careful when connecting and wiring power or signal lines on your system. Radiated noise from nearby electronic drives can interfere with feedback, communications, or other sensitive low-voltage signals. This prevents 1394C-SJT05-D from running successfully. Use shields on cables to minimize radiated noise, and don't forget to connect all shields to a single ground point. Refer to the manual for more information. Ensure that the open shielding layer (the rotary transformer feedback cable on the rotary transformer and the speed command cable on the servo driver) is insulated to avoid grounding loops.
1394C-SJT05-D Axis of AC Servo Controller is an axis used to control motor movement in an AC servo controller. It is an important part of the AC servo controller, which is used to achieve precise position, speed and torque control of the motor.
1394C-SJT05-D AC servo controller shaft usually has the characteristics of high precision, high speed, high response, etc., to achieve accurate position control and speed control. They are widely used in industrial automation, robots, CNC machine tools, printing equipment, packaging equipment and other fields.
In an AC servo controller, the shaft typically detects the position and speed of the motor via an encoder or other position sensor and feeds these signals back to the controller. The controller calculates the required control signal based on the feedback signal and outputs it to the power converter to control the motion of the motor.
1394C-SJT05-D AC servo controller shaft control mode usually includes position control, speed control and torque control. In position control mode, the shaft controls the motor's movement according to the set position instructions to achieve accurate position control. In the speed control mode, the shaft controls the motor's movement according to the set speed instruction to achieve precise speed control. In torque control mode, the shaft controls the output torque of the motor according to the set torque instructions to achieve precise torque control.
In short, the AC servo controller shaft is an important part of the AC servo controller used to control the motor movement, with high precision, high speed, high response and other characteristics, to achieve accurate position, speed and torque control.
