Brand: BENTLY
Model: 147663-01
Product type: VGA I/O module
Size: 3x12x24cm
Weight: 0.55kg
Payment method: Wire transfer, Western Union
Port of shipment for remittance: Xiamen, China
Delivery time: 1-3 working days
Condition: New and 100% original
Warranty: 12 months
147663-01 Main functions:Data communication: Facilitates communication between the 3500 system and VGA display.
Data visualization: Enables VGA display to display a variety of system information:
1. System status
2. Sensor reading
3. Machine operation data
4. Alarm notification
147663-01 Product features：
Use 3500 Rack configuration software to configure the language and VGA display type of the 3500/94 module. All other types of data configuration are done locally on the display, giving the operator control over the data displayed. Locally, you can set up 9 custom screens.
For example, one custom screen can display all 1X measurements, while another screen can display all gap values, or custom screens can be organized into machine system groups. You can organize all system data into any specified set and then assign the data to a custom screen.
An API-670-compatible screen is also available. This screen displays a "3300 Style" bar chart and values for each rack slot display. Each module displays direct or gap values, as well as OK and bypass leds.
147663-01 Features：Visual data: Connect to a standard VGA monitor to display critical machine health information from the 3500 system [Machine Health, visualization].
Touch screen control: enables the operator to interact with the displayed data using a touch screen interface for intuitive operation [user interface, touch screen].
Customizable screens: Nine configurable screens are available that allow users to personalize data visualizations according to specific needs (user interface, customization).
Multilingual support: Adapt to different language preferences of global applications [internationalization].
