1756-CPR2U | Right Angle redundant power cable | with various additional functions

Manufacturer: Rockwell Automation

Brand; Alan Bradley

Part Number/Catalog number: Model 1756-CPR2U

Series: ControlLogix

Cable Length :3 ft (0.91 m)

Length :3 m (10 ft)

Weight :0.2 kg (0.3 lb)

The Allen-Bradley 1756-CPR2U is a 1756 right-angle redundant power cable for transferring power in ControlLogix systems. Compared with standard power supplies, redundant power supplies have various additional functions. Some of these are automatic chassis load sharing, operating status indicators, solid-state relays, and operating exceptions limited to the power supply (excluding cables and adapters).

The 1756-CPR2U redundant power cable has a cable length of 0.91 m (3 ft) and a weight of 0.3 lb. It has an input current of 970 mA (5.1V DC), 1.7 mA (24V DC). It supports ControlNet communications at speeds of up to 5 megabits per second. The 1756-CPR2U has a maximum power consumption of 5.1W and a heat dissipation of 17.4 BTU/ hour. It is installed in a 4-inch case with an open housing. (101.6 mm) clearance between top and side.

The 1756-CPR2U redundant power cable has reduced the minimum installation length required for redundant power supplies from more than 5 inches (152.4 mm) to less than 2 inches (50.8 mm). It supports all families of standard redundant power supplies in ControlLogix systems. XT cable adapters and power supplies are compatible. The 1756-CPR2U is RoHS (Restriction of Hazardous Substances) compliant and costs the same as other standard cables.
