The AB 1756-DMF30 is a ControlLogix SynchLink driver interface module from Allen-Bradley. It allows users to connect the Reliance Electric SF3000 distributed power supply system 10612598282804 to the ControlLogix controller. The 1756-DMF30 provides a single point of connection between two systems, making it easy to integrate them into a single control system.
Specifications:
Input voltage range: 10-30V DC
Input current: 20mA per channel
Input impedance: 10kΩ per channel
SynchLink Communication rate: 1Mbps
DF1 communication rate: 19.2kbps
CIP communication rate: 100Mbps
Standard I/O: 8 discrete inputs, 8 discrete outputs
Extended I/O: 16 discrete inputs, 16 discrete outputs
Features:
Connect the Reliance Electric SF3000 distributed power system to the ControlLogix controller
Provides a single point of connection between two systems
Simplify the integration of two systems into a single control system
Supports the SynchLink communication protocol
DF1 and CIP protocols are supported
Support for standard and extended I/O
