Manufacturer Rockwell Automation
Brand Allen Bradley
Part Number/Catalog Number: 1756-IF16HK
Series ControlLogix
Module Type HART analog input module
Allen Bradley's 1756-IF16HK offers a wide range of features and is easy to automate; It belongs to the HART analog input module family and has a high resolution of 16 to 21 bits for clear message display. The device may be vulnerable to overvoltage, but the overvoltage protection feature of this particular device can protect the machine from damage through its 8-volt DC capacity. In addition, the device can operate continuously up to 50 volts in terms of isolation voltage.
The 1756-IF16HK models are equipped with the ControlLogix Hart module, which supports maximum system performance through the combination of real-time HART data. Enhanced insight into equipment status simplifies debugging, operation, and maintenance of automated programs. It has an open housing and a maximum power consumption of 60 watts at 5.2 degrees Celsius.
This particular model of coating is conformal, covering the outline of the board with a thin polymer film to protect against moisture, chemicals, dust and high temperatures. In the event of system and field failures, the model includes comprehensive I/O diagnostics.
