Manufacturer Rockwell Automation
Brand Allen Bradley
Part number/Catalog number 1756 IF16IHK
Series ControlLogix
Module Type HART interface module
Allen Bradley 1756-IF16IHK products are primarily used to confirm and monitor digital and analog data from HART devices. This model of digital I/O module can be operated from any remote workstation and the channel can be viewed from a single location.
This particular type of HART device has 16 input channels. It can also be very easily installed on the ControlLogix chassis. Notice that all field side wiring available in the 1756-IF16IHK is either detachable terminal or based on the 1492 connector; This feature allows users to connect all remote field side cabling without any failures.
The 1756-IF16IHK is supported by HART primary, secondary, third and fourth values and can be used as a controller label in control applications.
This device is very beneficial, allowing users to connect directly to HART devices without the help of any type of external multiplexer or additional wiring.
| A-B 80190-220-01-R Mitsubishi IGCT Module |
| A-B Touch panel 2711-B6C20 Panelview 600 HMI Module |
| A-B 80190-300-01-R Mitsubishi 8019030001R IGCT Module |
| A-B 1753-L32BBBP8A Allen Bradley PLC GuardPLC 1753L32BBBP8A |
| ALLEN BRADLEY 80190-560-01-R Controller Circuit Board |
| MITSUBISHI/A-B SCR 81001-450-53-R IGCT three-piece set 8100145053R |
The input current range of this particular module is 0 to 20 mA and 4 to 20 mA at 5.1 V DC, while its surge current capacity can be measured up to 400 mA at 5.1 V DC and 450 mA at a maximum of 24 V DC.
