1756-IM16IK Isolated digital input module Allows users to easily configure from a remote location

No.1756-IM16IK
Manufacturer Rockwell Automation
Brand Allen Bradley
Part Number/Catalog Number 1756-IM16IK Series
Series ControlLogix
Module type Isolated digital input module
Enter 16 separate isolated inputs
Input voltage 240 volts AC
  • 1756-IM16IK    Isolated digital input module Allows users to easily configure from a remote location
Desciption
Manufacturer Rockwell Automation
Brand Allen Bradley
Part Number/Catalog Number 1756-IM16IK Series
Series ControlLogix
Module type Isolated digital input module
Enter 16 separate isolated inputs
Input voltage 240 volts AC
Allen Bradley's 1756-IM16IK isolated digital input module comes with 16 separate isolated inputs. The input voltage used is 240 volts AC, while the device operates in the voltage range of 159 to 265 volts AC. The input delay time of the device can be programmed to be 9 or 18 milliseconds. Its minimum operating current is 5 mA at 159 volts AC and 60 Hertz, and its maximum operating current is 13 mA at 265 volts and 60 Hertz. The maximum input current off state peak value of the device is 2.5 mA.



The isolated digital input module has a maximum power consumption capacity of 5.8 watts at 60 degrees Celsius. The backplane current at 5 V is 100 mA; At 24 volts, it's 3 mA. The module's conformal coating also protects the internal circuitry from dust, pollution, moisture and extreme temperatures.



1756-IM16IK allows users to easily configure and monitor digital and analog data of any connected HART device from a remote location; The data displayed for any given channel is clearly visible from a single location.



The device is equipped with HART 5, 6 or 7 read/write capabilities.
