Manufacturer Rockwell Automation
Brand Allen Bradley
Part Number/Catalog number 1756-L62S
Series ControlLogix
Module type GuardLogix controller
The 1756-L62S is an Allen-Bradley communication protocol module with unique communication advantages. The module is a GuardLogix controller with 4 MB of memory and 6 MB of safe memory. The GuardLogix controller module is a certified controller system for security applications. This GuardLogix controller system supports SIL3 and PLe security applications.
The GuardLogix controller brings together the host controller and security partner for unified functionality. The model has 4 MB of memory for standard tasks and 1 MB for security tasks and other similar components.
The intelligent and efficient key switch is located in front of the main controller, allowing easy operation of the controller mode. The 1756-L62S has a maximum I/O range of 128,000, while the maximum analog I/O range is 4000. The current consumption capacity is 1200 MA at 5.1V DC and 14 mA at 24V DC. Notably, the device has a power consumption of 3.5 watts and a heat dissipation of 11.9 BTU/ hour.
The device has a continuous isolation voltage capacity of 30 volts. It has no shell. The 1756-L62S is unique in that the chassis provides a physical connection between the GuardLogix controller and the module.
