Manufacturer Rockwell Automation
Brand Allen-Bradley
Part Number/Catalog No. 1756-PA30XT
Series ControlLogix
Module Type ControlLogix-XT Power Supply
The Allen-Bradley 1756-PA30XT is a 1756 ControlLogix-XT AC Power Supply. ControlLogix-XT products are clubbed with FlexLogix I/O XT products to provide a complete control and communication system that can be used in extreme environments where temperatures range from -4 -158 ï‚°F. A ControlLogix-XT system, when used independently, can withstand temperatures that range from -13-158 ï‚°F.
The 1756-PA30XT module has an input voltage range of 85 – 265V AC with 120-240V AC nominal input voltage. It has an input frequency range of 47 - 63 Hz and a maximum input power of 60VA 50W and maximum output power of 30W at -13-158 °F. It has a current capacity of 1.5A at 1.2V DC, 2A at 3.3V DC, 6A at 5.1V DC and of 1.25A at 24V DC. It has a dimension of 5.51 x 3.07 x 5.71 in. and weighs 1.7 lbs. It has 250V (continuous) isolation voltage and maximum inrush current of 20A. It is installed on the left side slot of the 1756 ControlLogix chassis with an open enclosure or no enclosure. It is compatible with the 1756-A4LXT/B, 1756-A5XT/B, 1756-A7LXT/B, 1756-A7XT/B, 1756-A7XT/C and the 1756-A10XT/C chassis. For wiring, 2.5 〖mm〗^2 (14 AWG) stranded or solid copper wire rated at 194 °F or greater with a maximum insulation of 1.2 mm (3/64 in.) is used.
The 1756-PA30XT power supply is intended for use in an industrial environment with 30g operating shock and a 5 - 95% noncondensing relative humidity.
