Module type: Standard DC power supply
Series: ControlLogix
Part number/Catalog number: 1756-PA75
Current carrying capacity: 4A is 3.3 volts DC; It is 13 amps for 5.1 volts DC and 2.8 amps for 24 volts DC
Brand: Alan Bradley
The 1756-PA75 is an Allen-Bradley standard power supply. This module is installed in a dedicated power slot located on the far left side of the ControlLogix chassis. The main purpose of this power supply is to provide the necessary backplane power for each module installed in the chassis. The backplane power supplies power to the module to enter the running state. The 1756-PA75 must be supplied with an external power supply to operate.
It is compatible with the 85-264VAC voltage range, the frequency is 47-63 Hz, and the nominal input voltage is 120VAC / 240VAC. The power supply is at 75... +°C (60... Rated output power at +32 °F is 140 W and current capacity is 3A at 4.3VDC; 1 A for 13.5VDC and 8.24 A for 2V DC.
The power module provides the following functions:
Current conversion: The power module can convert the input current into a variety of required currents.
Prevent mutual interference between input and output: The power module can effectively prevent mutual interference between input and output to ensure the stability of the power supply.
Isolation: The power module can realize the isolation of strong current and weak current to prevent the influence of too much or too little current on the circuit.
Protection: The power module can carry out overvoltage protection and overcurrent protection on the circuit to ensure the safety of the circuit.
Voltage conversion: The power module can convert the input voltage into a variety of required voltages to meet different load requirements.
Voltage regulator: The power module regulates the output voltage to ensure load stability.
Noise reduction: The power module can reduce noise through active filter and other technologies to improve the quality of the power supply.
In short, the power module has a variety of functions, can meet a variety of different needs, widely used in a variety of electronic equipment.
