1769-L35CR controller
The 1769 CompactLogix controller provides advanced control in the form of a distributed control package
Control, communication and I/O components.
1769-L35CR For a more flexible system:
• Use multiple controllers in a single rack.
1769-L35CR controller
The 1769 CompactLogix controller provides advanced control in the form of a distributed control package
Control, communication and I/O components.
1769-L35CR For a more flexible system:
• Use multiple controllers in a single rack.
• Use multiple controllers connected across the network.
• Use multiple platforms distributed in multiple places and connected via multiple I/O links
I/O.
CompactLogix Controller is a member of the Logix family of controllers, offering compact,
A powerful and cost-effective system that consists of:
• RSLogix™ 5000 programming software
Implement EtherNet/IP (1769-L32E and 1769-L35E only) and ControlNet
(1769-L32C and 1769-L35CR only) A built-in communication port for the network
• 1769-SDN for I/O control and remote device configuration via DeviceNet
1769-L35CR Communication interface module
• Built-in serial port on each CompactLogix controller
• Compact DIN rail mounted or panel mounted I/O systems
Type I/O module
When designing a CompactLogix system, you need to determine the network configuration and placement of components
Buy. To design a CompactLogix system, you must select the following:
• I/O devices
• Communication network
• Controller
• Power supply
• Software
