Part Number/Catalog number: 2094-BC04-M03-M

Module position: leftmost of the power rail

Internal shunt peak power :22.5 kW

Internal parallel continuous power supply :200 watts

PWM frequency :4 KHZ

Bandwidth Speed loop: 500 Hz Current loop: 1300 Hz

Input voltage range :400/460 volts AC

Inverter part output current :30 amps

Converter part output :28 kW

Power consumption :94-255 watts

Operating temperature :32-122 F (0-50 C)

Product description: Integrated shaft module

Manufacturer: Rockwell Automation


2094-BC04-M03-M This module has a converter and an inverter section. The inverter part has an output rated power of 28kW and the inverter has a rated output of 30 amps. The module is also known as the additive manufacturing power module. It comes with a wiring plug connector set for motor power (MP) and motor/resistance braking power (BC). 2094-BC04-M03-M The module does not provide connector kit input and output interfaces, safety and auxiliary feedback signals, catalog numbers 2090-K6CK-D44M and 2090-K6CK-D44S0, and motor feedback catalog number 2090-K6CK-D15M.


When using this module, it is not always necessary to ground jumper Settings. However, ungrounded or high-impedance power supply configurations require ground jumper Settings. To set the ground jumper Settings, 2094-BC04-M03-M Remove the Integrated Access Module (IAM) from the power rail, turn on the power module and change the jumper position to the appropriate position. By default, the module is set to the ground position, where P16 and P17 are short-circuited, while ungrounded terminals P18 and P19 are short-circuited.
