Model: 2094-PRS1
Category: Ultra-thin power rail
The quality of gold or silver; New, not new
Stock: available
Brand: A-B
Application of 230 or 460 volt drive systems
Component Capacity One IAM
Weight 2.3 lb (1.05 kg)
Description
Allen-Bradley's 2094-PRS1 Kinetix 6000 Slim Power Rail supports a single integrated shaft module (IAM), but no other modules. The 2094-PRS1 comes with a 2094 mounting bracket for mounting the 2094-PRS1 on the AC line filter. The 2094-PRS1 is a single-inverter slot power rail limited to Kinetix 6000 systems with single-slot requirements. The connector pins of a single inverter slot are covered with a protective cover that prevents the slot pins from being damaged and prevents unwanted entities from entering the slot. 2094- The PRS1 Kinetix 6000 power rail measures 134.6 mm (5.3 in) x 88.9 mm (3.5 in) with a total weight of 1.05 kg (2.3 lb). The 2094-PRS1 power rail is compatible with the Kinetix 6000 system, Kinetix 6000M, Kinetix 6200 and Kinetix 6500 drive systems, making it a perfect fit. It has an ambient temperature of 0-50 °C (32-122 °F) and an ambient relative humidity of 5-95% non-condensing. The 2094-PRS1 is c-UL-us, CE and IEC 61508: Part 1-7:2000 (Functional Safety Certification) certified to operate at altitudes of up to 1000 m (3,281 ft) without reducing power rating. It can also withstand operating shocks of about 15G and will also maintain a maximum operating vibration of 55G at 2-55Hz.
