2098-DSD-HV030-SE | Digital servo drive module with optical fiber SERCOS command interface

Model: 2098-DSD-HV030-SE

Bus overvoltage: 810 volts DC

Contact output: one (1) A-type contact

Index: No

Sercos: Yes

Shunt off: 750 volts DC

Shunt open: 800 volts DC

Continuous output power @ 480 VAC 3.0 kW

Continuous output power @ 230 VAC 1.5 kW

Brand: Alan Bradley

Input voltage (AC) : 230-480 voltage RMS, 3 phases

The 2098-DSD-HV030-SE is an Ultra 3000 digital servo driver module with fiber SERCOS command interface. The module can be used in a variety of motion control applications and architectures. There are two SERCOS fiber optic cables in this module. The AC input voltage range of the module is 230-480V AC (three-phase). The AC input frequency of the module is 47-63 Hz. The bus capacitance of the module is 470 μF. The module has an internal shunt resistance of 120 ohms. The module has SERCOS communication rates of 4 and 8 Mbps. The node address ranges from 01 to 99. The module contains components and assemblies that are sensitive to ESD (electrostatic discharge). Follow static control precautions when installing, testing, repairing, or repairing this component. Allen-Bradley 2098-DSD-HV030-SE weighs 8.55 kg (18.8 lb). The module is 9.54 x 14.2 x 5.46 inches. (242.2 x 360.7 x 138.7 mm). The module has a relative humidity of 5-95% and no condensation. The module operates at A temperature of 0-55 °C (32-131 A °F). The module has a storage temperature of -40-70 °C (-40-158 °F). Allen-Bradley 2098-DSD-HV030-SE has an operating shock of 15 g (3 pulses, 11 ms). The module has a non-operating shock of 30 g (3 pulses, 11 ms). The module is designed to maintain optimal function at 2.5g vibration. The module can operate at altitudes of up to 1,000 meters (3,280 feet) without derating.
