Basic information
Model: 2711-K3A10L1
Manufacturer: Rockwell Automation
Product line: PanelView 300 standard operator terminal
2. Technical specifications
Display screen:
Size: 3 inches
Type: Monochrome transreflection LCD with LED backlight
Resolution: 128 x 64 pixels
Display area: 73 mm (W) x 42 mm (H) or 2.87 inches (W) x 1.67 inches (H)
Backlight life: Estimated to be up to 100,000 hours
Power Supply:
Voltage range: External 18-32V DC power supply voltage supply (nominal 24V DC)
Communication interface:
Embedded: DeviceNet communication interface
Other: RS232 printer port
Memory:
Application runtime memory: 170 KB
Nonvolatile memory: 240 KB (for application objects, text, and bitmaps)
Keyboard and interface:
Function keys: 8 (F1... F8)
Other keys: cursor key, numeric input key
Housing and protection level:
Housing type: NEMA type 12/13, 4X (for indoor use only), IP54, IP65
Functional characteristics
Strong man-machine dialogue ability: all Chinese interface, friendly interface.
Fast analysis speed, high precision: microcomputer control, measurement results directly display and calculate.
Easy operation: High efficiency, full automation of the test process.
Fault self-diagnosis and information display: with the instrument fault self-diagnosis, status information display and other functions.
Printing function: Equipped with 20-character thermal printer, paper width 58 mm.
4. Application and compatibility
Application scenario: As an operator terminal, it is used to interact with the machine and perform monitoring and control tasks.
Compatibility: Support ATA memory card, can communicate with partner devices, exchange data.
