Model: 2711-T10C9
Product series: PanelView standard terminals
Product type: PanelView 1000 Standard operation terminal
Display type: Active Matrix thin film resistor (TFT) with cold cathode fluorescence (CCF) backlight
Display area: 211 x 158 mm (8.3 x 6.2 in)
Resolution: 640 x 480 pixels
Backlight: 100,000 hours LED backlight life
Touch screen: 384 (24 columns x 16 rows)
Touch Cell size: 26 x 30 pixels
Application memory: 1008K bytes (application screen)
Communication port: DH485; RS232 (Printer)
Input voltage range: 85... 264V AC, 47... 63 Hertz
Operating temperature: 0... 55°C (32... 131°F)
Description
The Allen-Bradley 2711-T10C9 is part of the PanelView Plus 1000 color operating terminal.
2711-T10C9 Color display allows you to view the configuration environment of the terminal and the operating interface of the operating terminal. With an active matrix thin film resistor (TFT) with a cold cathode fluorescence (CCF) backlight, the operating terminal can be used to display full-color graphics and display advanced information at a glance. Color screens can be used to display the status of instruments and equipment, describing process areas, materials and plant conditions. The embedded analog resistive touch screen interface is designed to allow the operator to interact directly with the runtime objects displayed on the screen. This is a more convenient way to operate the 2711-T10C9 compared to the keyboard terminals.
The 2711-T10C9 has an embedded power terminal block at the rear of the unit. It is powered by an external voltage supply of 85-264VAC at a frequency of 43-63 Hz. It has a maximum power consumption of 55 VA and a cooling power of 39 W (132 BTU/HR).
