| Product Model | 3500/70M-01-00 |
| Manufacturer | Bently Nevada |
| Product Type | Vibration Monitoring Module |
| Input Type | Proximity probes, accelerometers |
Product Overview
The BENTLY 3500/70M-01-00 is a high-performance vibration monitoring module designed for critical rotating machinery protection. As part of the Bently Nevada 3500 Series, the 3500/70M-01-00 provides reliable, continuous monitoring of vibration, shaft position, and related process signals, ensuring early detection of mechanical faults and enabling predictive maintenance. This module is ideal for turbines, compressors, pumps, and generators in power generation, petrochemical, and industrial applications.
The 3500/70M-01-00 integrates seamlessly with other 3500 Series components, offering high accuracy, stability, and diagnostic capabilities in a compact form factor. Its rugged design and advanced signal processing ensure consistent performance in harsh industrial environments, supporting long-term reliability and safety.
Hainan Jinlin Mechanical & Electrical is a trusted distributor of industrial control and monitoring equipment. Leveraging deep industry expertise, we provide professional pre-sales guidance and post-sales technical support, ensuring high-quality service and satisfaction.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | 3500/70M-01-00 |
| Manufacturer | Bently Nevada |
| Product Type | Vibration Monitoring Module |
| Input Type | Proximity probes, accelerometers |
| Measurement Range | ±50 mils peak-to-peak |
| Frequency Range | 0.5–10 kHz |
| Alarm Functions | High, low, and shutdown alarms |
| Mounting Type | Rack-mounted module (3500 Series chassis) |
| Operating Temperature | -40°C to +85°C |
| Communication Interface | Serial / 3500 Series bus |
Key Features and Benefits
The BENTLY 3500/70M-01-00 provides comprehensive machinery protection with precise vibration and shaft position measurement. Its advanced signal processing ensures accurate detection of imbalance, misalignment, bearing wear, and other mechanical issues. The module supports multiple alarm thresholds, enabling both alert and shutdown signals to prevent catastrophic equipment failure.
Designed for seamless integration within the 3500 Series monitoring system, the 3500/70M-01-00 provides continuous real-time monitoring, historical data logging, and system diagnostics. Its robust construction ensures operation in high-vibration, high-temperature, and high-humidity environments without compromising measurement accuracy. The module also allows straightforward calibration and maintenance, reducing downtime and operational costs.
With its combination of precision, reliability, and diagnostic capabilities, the 3500/70M-01-00 is essential for condition-based monitoring, predictive maintenance programs, and critical machinery protection in power plants, refineries, and industrial manufacturing facilities.
Related Models
3500/72M-01-00 – Enhanced vibration module with extended frequency range.
3500/76M-01-00 – Multi-channel vibration monitoring for complex machinery.
3500/70M-02-00 – Firmware-upgraded version with advanced diagnostics.
3500/71M-01-00 – Compatible shaft displacement module for the 3500 system.
3500/60M-01-00 – Analog vibration module with standard alarm capabilities.
3500/65M-01-00 – High-speed monitoring module for turbine applications.
3500/77M-01-00 – Expansion module for additional input channels.
3500/70M-01-01 – Ruggedized version for extreme operating conditions.
3300 XL Series Modules – Older series compatible for legacy systems integration.
3500/64M-01-00 – Vibration monitoring module optimized for pumps and compressors.
Typical Application Areas
Power Generation: Turbines, generators, and auxiliary rotating equipment.
Oil & Gas: Compressors, pumps, and critical rotating machinery protection.
Petrochemical & Chemical: Process machinery vibration monitoring.
Industrial Manufacturing: High-speed motor and gearbox condition monitoring.
All products are backed by a one-year warranty and comprehensive pre-sales and after-sales support. If the model you require is unavailable, please contact us directly for expert assistance.
