Model: 3BHB002483R0001 USC329AE01
Brand Name: ABB
Certification: Canada
Application: Nuclear power plant
Delivery time: In stock
Description: ABB
Weight: 4 pounds
Origin: Sweden
Dimensions
Product Net Width:160 mm
Product Net Height:140 mm
Product Net Depth / Length:250 mm
Product Net Weight:2.977 kg
System highlights
- Maintenance free busbar construction
- Easy switchgear extension
- Main busbar arrangement at the rear thus assuring
- maximum safety to personnel
- effective withstand against highest stresses in case of
short circuit
- optimum heat dissipation
- Gas tight seals for connection from the equipment compartment to the main busbar system
- Option for Form 4 separation for both incoming and
outgoing assemblies
- Active and passive arc fault prevention tested according
to IEC 61641
- Isolating materials are free of CFC and halogens
Module options
Available options for the selection of MStart modules are:
- Starter types:
Non-reversing Direct Online (NR-DOL)
Reversing Direct Online (REV-DOL)
Heavy Duty (HD)
Star-Delta (NR-S/D)
Contactor Feeder (CF)
Feeder (Energy distribution module)
- Rated voltages: 400V, 500V, 690V
- Short circuit protection device (SCPD): fused, fuseless
For more information on the available module types, please
refer to the module selection tables in the Technical Data
section.
Withdrawable modules MStart
The withdrawable design of MStart provides a maximum of
plant and operator safety.
As per definition in IEC 61439 series, withdrawable modules
can be electrically connected and disconnected (“withdrawn”).
This is applicable to the main incoming circuit, the main outgoing circuit as well as the auxiliary circuits. MStart modules
can be withdrawn without the help of a specific tool.
MStart are standardized components, ready-to-use and
offered for a wide range of motor starter ranges and applications leading to maximum flexibility.
The high device packing density allows a comparatively low
footprint of the MCC.
